YASKAWA FP65U T Series User Manual

4 Receiving
YASKAWA TOEPC7106171FD FP605 DRIVE INSTALLATION & PRIMARY OPERATION 11
No. Description
5 EMC filter
• A: No built-in EMC filter
• C:Built-in EMC filter for C2
6 Protection design
• B: IP20/UL Open Type
• F: IP20/UL Type 1
• V: IP55/UL Type 12
• W: IP55/UL Type 12 Heatsink External Mounting
7 Environmental specification
A: Standard
■ Rated Output Current
Table 4.2 and Table 4.3 give the rated output current values.
Note:
• These output current values are applicable for drives that operate at standard specifications.
• Derate the current in applications that:
–Increase the carrier frequency
–Have high ambient temperature
–Use side-by-side installation.
Table 4.2 Output Current for Three-Phase AC 208 V Class Models (NEMA Rating)
Model
Maximum Applicable Motor Output
kW (HP)
Rated Output Current
A
2011 2.2 (3) 10.6
2017 3.7 (5) 16.7
2024 5.5 (7.5) 24.2
2031 7.5 (10) 30.8
2046 11 (15) 46.2
2059 15 (20) 59.4
2075 18.5 (25) 74.8
2088 22 (30) 88
2114 30 (40) 114
2143 37 (50) 143
2169 45 (60) 169
2211 55 (75) 211
2273 75 (100) 273
2343 90 (125) 343
2396 110 (150) 396
Table 4.3 Output Current for Three-Phase AC 480 V Class Models (NEMA Rating)
Model
Maximum Applicable Motor Output
kW (HP)
Rated Output Current
A
4005
2.2 (3)
4.8
4008
3.7 (5)
7.6
4011
5.6 (7.5)
11
4014
7.5 (10)
14
4021
11.2 (15)
21
4027
15 (20)
27
4034
18.6 (25)
34
4040
22 (30)
40
