YASKAWA GA50U Series

14 European Standards
160 YASKAWA TOEPC71061752B GA500 Drive Installation & Primary Operation
WARNING
Electrical Shock Hazard. Ground the neutral point on the power supply of drive models
BxxxE, 2xxxE, and 4xxxE to comply with the EMC Directive before you turn on the EMC filter or if there is high
resistance grounding. If you turn ON the EMC filter, but you do not ground the neutral point, it can cause serious
injury or death.
External EMC Noise Filter Selection
Table 14.12 External EMC Noise Filter (BxxxA)
Drive model EMC Noise Filter Model Quantity Manufacturer
B001 FS23638-10-07 1 Schaffner
B002 FS23638-10-07 1 Schaffner
B004 FS23638-10-07 1 Schaffner
B006 FS23638-20-07 1 Schaffner
B010 FS23638-20-07 1 Schaffner
B012 FS23638-30-07 1 Schaffner
B018 FS23638-40-07 1 Schaffner
Table 14.13 External EMC Noise Filter (2xxxA)
Drive model EMC Noise Filter Model Quantity Manufacturer
2001 FS23637-8-07 1 Schaffner
2002 FS23637-8-07 1 Schaffner
2004 FS23637-8-07 1 Schaffner
2006 FS23637-8-07 1 Schaffner
2010 FS23637-14-07 1 Schaffner
2012 FS23637-14-07 1 Schaffner
2021 FS23637-24-07 1 Schaffner
2030 FS5973-35-07
*1
1 Schaffner
2042 FS5973-60-07
*1
1 Schaffner
2056 FS5973-100-07
*1
1 Schaffner
2070 FS5973-100-07
*1
1 Schaffner
2082 RTEN-5200 1 TDK
*1 When you install an external EMC noise filter, change the terminals or use the junction terminal.
Table 14.14 External EMC Noise Filter (4xxxA)
Drive model EMC Noise Filter Model Quantity Manufacturer
4001 FS23639-5-07 1 Schaffner
4002 FS23639-5-07 1 Schaffner
4004 FS23639-5-07 1 Schaffner
