12 Drive Control, Duty Modes, and Programming
YASKAWA TOEPC71061752B GA500 Drive Installation & Primary Operation 87
No.
(Hex.)
Name Description
H3-02
(0434)
Terminal A1 Function
Selection
Sets the function for MFAI terminal A1.
H3-03
(0411)
RUN
Terminal A1 Gain
Setting
Sets the gain of the analog signal input to MFAI terminal A1.
H3-04
(0412)
RUN
Terminal A1 Bias
Setting
Sets the bias of the analog signal input to MFAI terminal A1.
H3-09
(0417)
Terminal A2 Signal
Level Select
Sets the input signal level for MFAI terminal A2.
0 : 0-10V (LowLim=0)
2 : 4 to 20 mA
3 : 0 to 20 mA
4 : -10 to +10V (Bipolar Reference)
H3-10
(0418)
Terminal A2 Function
Selection
Sets the function for MFAI terminal A2.
H3-11
(0419)
RUN
Terminal A2 Gain
Setting
Sets the gain of the analog signal input to MFAI terminal A2.
H3-12
(041A)
RUN
Terminal A2 Bias
Setting
Sets the bias of the analog signal input to MFAI terminal A2.
H3-13
(041B)
Analog Input
FilterTime Constant
Sets the time constant for primary delay filters on MFAI terminals.
H3-14
(041C)
Analog Input Terminal
Enable Sel
Sets the enabled terminal or terminals when H1-xx = C [MFDI Function Select
= Analog Terminal Enable Selection] is ON.
1 : Terminal A1 only
2 : Terminal A2 only
7 : Terminals A1 and A2
H4-01
(041D)
Terminal AM Analog
Output Select
Sets the monitoring number to be output from the MFAO terminal AM.
H4-02
(041E)
RUN
Terminal AM Analog
Output Gain
Sets the gain of the monitor signal that is sent from MFAO terminal AM.
H4-03
(041F)
RUN
Terminal AM Analog
Output Bias
Sets the bias of the monitor signal that is sent from MFAO terminal AM.
H4-07
(0423)
Terminal AM Signal
Level Select
Sets the MFAO terminal AM output signal level.
0 : 0-10V
2 : 4 to 20 mA
