3 Electrical Installation
12 TOEP C710606 27 J1000 Quick Start Guide
Wiring Specification
Main Circuit
Use the fuses and line filters listed up in the table below when wiring the main circuit. Make
sure not to exceed the given tightening torque values.
Tightening Torque Values
Tighten the main circuit terminals using the torque values provided by the table below.
Control Circuit
Use wires within the specification listed below. For safe wiring use solid wires or flexible
wires with ferrules. The stripping length or ferrule length should be 6 mm.
Model
CIMR-JC
EMC Filter Type
Main Fuse
(Ferraz)
Recom.
Motor cable
[mm²]
Main Circuit Terminal Sizes
Schaffner
R/L1,S/L2,T/L3, U/T1,
V/T2,W/T3, - , +1, +2
B1, B2 GND
BA0001 FS23638-10-07 A6T15 2.5 M3.5 M3.5 M3.5
BA0002 FS23638-10-07 A6T20 2.5 M3.5 M3.5 M3.5
BA0003 FS23638-10-07 A6T20 2.5 M3.5 M3.5 M3.5
BA0006 FS23638-20-07 A6T40 2.5 M4 M4 M4
BA0010 FS23638-20-07 A6T40 4 M4 M4 M4
2A0001 FS23637-8-07 A6T10 2.5 M3.5 M3.5 M3.5
2A0002 FS23637-8-07 A6T10 2.5 M3.5 M3.5 M3.5
2A0004 FS23637-8-07 A6T15 2.5 M3.5 M3.5 M3.5
2A0006 FS23637-8-07 A6T20 2.5 M3.5 M3.5 M3.5
2A0010 FS23637-14-07 A6T25 2.5 M4 M4 M4
2A0012 FS23637-14-07 A6T30 4 M4 M4 M4
2A0020 FS23637-24-07 A6T40 6 M4 M4 M4
4A0001 FS23639-5-07 A6T10 2.5 M4 M4 M4
4A0002 FS23639-5-07 A6T10 2.5 M4 M4 M4
4A0004 FS23639-5-07 A6T20 2.5 M4 M4 M4
4A0005 FS23639-10-07 A6T25 2.5 M4 M4 M4
4A0007 FS23639-10-07 A6T25 2.5 M4 M4 M4
4A0009 FS23639-10-07 A6T25 2.5 M4 M4 M4
4A0011 FS23639-15-07 A6T30 2.5 M4 M4 M4
Terminal Size M3.5 M4
Tightening Torque [Nm] 0.8 to 1.0 1.2 to 1.5
Terminal Screw Size
Tightening
Torque N·m
Bare Wire Terminal Ferrule-Type Terminal
Applicable wire
size mm
2
Recomm.
mm
2
Applicable wire
size mm
2
Recomm.
mm
2
MA, MB, MC M3 0.5 to 0.6 0.25 to 1.5 0.75 0.25 to 1.0 0.5
S1-S5, SC, +V, A1,
AC, AM
M2 0.22 to 0.25 0.25 to 1.0 0.75 0.25 to 0.5 0.5
