YASKAWA Motoman YRC1000micro

1 Outline
1.1 System Configuration
1-2
HW1485152
HW1485152
The following diagram shows an example of the configuration of a system
with an SST-PN-2-PE board used in PROFINET master and PROFINET
slave simultaneously.
HUB
PROFINET
IO Controller/
IO㻌Device
SST-PN-2-PE
PROFINET IO Controller
YRC1000micro Controller
PROFINET Cable
PROFINET IO Device
External PLC (MADE BY Siemens)
13/47
