2 Hardware Specifications
2.2 Board Specifications
2-2
HW1485152
HW1485152
2.2 Board Specifications
2.3 Communication Specifications
Items Specifications
Interface to the external
device
PROFINET
Board mounting position Option PCI Express slot on the YRC1000micro
Error indicator LED display
Number of transmission I/O
points
Maximum number of I/O points for SST-PN-2-PE:
Input: 1008 points; Output: 1008 points
Note on Transmission I/O Points
1. Input points and output points cannot be configured indi-
vidually.
2. YRC1000micro has 1024 inputs and 1024 outputs pre-
pared for the I/O board.
Of these, 8 inputs and 8 outputs are pre-allocated.
In addition, 8 I/O points per channel are required for SST-
PN-2-PE communication status.
The remaining number of I/O points are available for
transmission.
3. Fewer I/O points may be available than the number listed
above depending on the I/O allocation method configured
with the setting tool for the SST-PN-2-PE board, condi-
tions, and other factors.
Items Specifications
Transmission speed 10Mbps/100Mbps
Transmission media PROFINET cable
