5 Installation Procedure
YASKAWA ELECTRIC TOBP C730600 75B YASKAWA AC Drive Option PG-B3 Installation Manual 19
Table 3 Parameter Settings and Connections for Different Encoder Types
PG Encoder type Control Method
Number of PG
Encoders
F1-21 Setting F1-37 Setting
Single-Pulse (A)
V/f w/PG
10 N/A
2N/A 0
CLV
1N/A N/A
2N/A N/A
Two-Pulse (AB Quadrature)
V/f w/PG
11 N/A
2N/A 1
CLV
1 None Required None Required
2 None Required None Required
Two-Pulse with Z Marker
V/f w/PG
11 N/A
2N/A 1
CLV
1 None Required None Required
2 None Required None Required
