5 Installation Procedure
28 YASKAWA ELECTRIC TOBP C730600 75B YASKAWA AC Drive Option PG-B3 Installation Manual
6. Replace and secure the LED Status Ring board (F) and the front cover of the drive
(D) including the keypad (E).
Figure 18
Figure 18 Replace the LED Status Ring Board, Front Cover, and Keypad
F
D
E
Install the keypad to the drive after replacing
the keypad connector and then the keypad
connector. At that time, insert the keypad
connector tab into the drive.
Keypad
connector
Tab
A1000
