9.2 List of Parameters
9.2.2 List of Parameters
9-38
Pn633
2
Input Signal Selections
13
0000h to
FFFFh
– 8888h All
After
restart
Setup –
Pn634
2
Input Signal Selections
14
0000h to
0013h
– 0002h All
After
restart
Setup –
Continued on next page.
Continued from previous page.
Parameter
No.
Size
Name
Setting
Range
Setting
Unit
Default
Setting
Applicable
Motors
When
Enabled
Classi-
fication
Refer-
ence
n.X
/JOG1 (Jog Speed Table Selection Input 1) Signal Allocation Reference
0 Active when CN1-40 input signal is ON (closed).
page 6-3
1 Active when CN1-41 input signal is ON (closed).
2 Active when CN1-42 input signal is ON (closed).
3 Active when CN1-43 input signal is ON (closed).
4 Active when CN1-44 input signal is ON (closed).
5 Active when CN1-45 input signal is ON (closed).
6 Active when CN1-46 input signal is ON (closed).
7 The signal is always active.
8 The signal is always inactive.
9 Active when CN1-40 input signal is OFF (open).
A Active when CN1-41 input signal is OFF (open).
B Active when CN1-42 input signal is OFF (open).
C Active when CN1-43 input signal is OFF (open).
D Active when CN1-44 input signal is OFF (open).
E Active when CN1-45 input signal is OFF (open).
F Active when CN1-46 input signal is OFF (open).
n.X
/JOG2 (Jog Speed Table Selection Input 2) Signal Allocation Reference
0 to F
The settings are the same as for /JOG1 (Jog Speed Table Selec-
tion Input 1) Signal Allocation.
page 6-3
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X
SI8 Signal Selection Reference
0 Do not allocate an input signal to CN1-14 and CN1-15.
page 6-5
1
Allocate the CLR signal as the input signal to CN1-14 and CN1-
15.
2
Allocate the /DEC signal as the input signal to CN1-14 and CN1-
15.
3
Allocate the /RGRT signal as the input signal to CN1-14 and
CN1-15.
n.X
SI8 Signal Selection Logic Reference
0 Active when CN1-14 and CN1-15 input signal is ON (closed).
page 6-5
1 Active when CN1-14 and CN1-15 input signal is OFF (open).
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
