3.1.5 Discharging Time of the Main Circuit’s Capacitor
3-20
3.1.5 Discharging Time of the Main Circuit’s Capacitor
The following table shows the discharging time of the main circuit’s capacitor.
Input Voltage
Combinations
Discharging Time
[min.]
SERVOPACK Model:
SGDV-
Converter Model:
SGDV-COA
Three-phase
200 VAC
121H 2BAA 20
161H 3GAA
25
201H 3GAA
30
Three-phase
400 VAC
750J 3ZDA
5
101J 5EDA
10
131J 5EDA
10
