SERVO SELECTION AND DATA SHEETS
5.4.1 Servomotor Dimensional Drawings
246
5.4 Σ
-
Series Dimensional Drawings
This section presents dimensional drawings of the Σ-Series Servomotor, Servopack,
and Digital Operator.
5.4.1 Servomotor Dimensional Drawings 246.................................
5.4.2 Servopack Dimensional Drawings 289.................................
5.4.3 Digital Operator Dimensional Drawings 291.............................
5.4.1 Servomotor Dimensional Drawings
1) The dimensional drawings of the SGM Servomotors are broadly grouped into the follow-
ing four categories.
a) Incremental encoder, no brake (from page 247)
b) Incremental encoder, with brake (from page 252)
c) Absolute encoder, no brake (from page 257)
d) Absolute encoder, with brake (from page 262)
Motor capacities are available as 30 W (0.04 HP), 50 W (0.07 HP), 100 W (0.13 HP), 200
W (0.27 HP), 300 W (0.40 HP), 400 W (0.53 HP), 750 W (1.01 HP). These are grouped
into three categories, as follows:
• 30W (0.04 HP), 50W (0.07 HP), 100W (0.13 HP)
• 200W (0.27 HP), 300W (0.40 HP), 400W (0.53 HP)
• 750W (1.01 HP)
