YASKAWA SI-EP3

7 PROFINET Messaging
44 YASKAWA ELECTRIC TOBP C730600 89D YASKAWA AC Drive Option SI-EP3 Installation Manual
u Yaskawa Vendor-Specific Control and Status Words
n The Control Word and the Status Word
The contents of the Control Word and the Status Word are detailed in Table 11.
n Frequency Reference
Frequency Reference is a 16-bit word containing the desired output frequency.
n Output Frequency
Output Frequency is a 16-bit word containing the current output frequency of the drive.
Table 11 Yaskawa-Specific Control Word and Status Word
Yaskawa-Specific Control Word
<1> Bit 11 is not used for GA500.
Yaskawa-Specific Status Word
Bit Description Bit Description
0 Run bit 0 Running
1 Reverse run bit 1 Zero Speed
2EF0 2 Reverse Operation
3Fault Reset 3 Reset Signal Input Active
4DI1 4At Speed
5DI2 5 Ready
6DI3 6Alarm
7DI4 7Fault
8DI5 8 oPE Fault
9DI6 9Uv Return
10 DI7 10 2nd Motor
11 DI8 <1> 11 ZSV
12 Not Used 12 Not Used
13 Not Used 13 Not Used
14 Not Used 14 Net Reference
15 Not Used 15 Net Control
