1
Introduction
5
400V Top View
400V Bottom View
CN101:
Main Circuit
Power Supply
CN103:
DC Bus
Terminals
CN201: Control
Circuit Power Supply
CN7: USB
CN2: Encoder
CN8: HWBB
CN1:
SERVOPACK I/O
CN6A/B: Ethernet
CN102: Servo
Motor Power
CN115:
Dynamic Brake
