2 Product Overview
8 YASKAWA ELECTRIC TOBP C710606 21D YASKAWA AC Drive - V1000 Finless Installation Guide
■ Nameplate
Figure 1
Figure 1 Nameplate Information
■ Drive Model Identification
The V1000 finless drive type is indicated by the letter “J” or “L” in the AC drive model
designation code. Refer to the Quick Start Guide for complete model number information.
Figure 2 Understanding the Model Number
<1> The drive must be installed a control panel with a proper heat sink.
PRG : 1011
CIMR-VA2A0003JAA
YASKAWA ELECTRIC CORPORATION MADE IN JAPAN
:
: AC3PH 200-240V 50 / 60Hz 2.7A / 1.4A
: AC3PH 0-240V 0-400Hz 1.2A / 0.8A
: 0.6 kg
:
:
: E131457 IP20
PASS
MODEL
MAX APPLI. MOTOR : 0.75kW / 0.4kW REV : A
INPUT
OUTPUT
MASS
O / N
S / N
FILE NO
7J48
AC drive model
Max applicable motor
Input specifications
Output specifications
Mass
Lot number
Serial number
Software version
CIMR -
V
A
2
A
0001
J
A
A
Drive
V1000
Series
Region
Code
Voltage
Class
No.
Enclosure
Type
Environmental
Specification
Design
Revision
Order
Customized
Specification
Finless
(IP20) <1>
J
Finless
(IP00) <1>
L
Unit
No.
