5-76
U1-17
Terminal
A3 input
voltage
Monitors the input voltage
of the multi-function analog
input.
An input of 10 V corre-
sponds to 100%.
10 V: 100% (10 V)
(0 to ±10 V possible)
0.1% A A A A 050H
U1-18
Motor sec-
ondary cur-
rent (Iq)
Monitors the calculated
value of the motor second-
ary current.
The motor rated secondary
current corresponds to
100%.
10 V:Motor rated secondary
current)
(0 to ±10 V output)
0.1% A A A A 51H
U1-19
Motor excit-
ing current
(Id)
Monitors the calculated
value of the motor excita-
tion current.
The motor rated secondary
current corresponds to
100%.
10 V:Motor rated secondary
current)
(0 to ±10 V output)
0.1% No No A A 52H
U1-20
Output fre-
quency after
soft-start
Monitors the output fre-
quency after a soft start.
The frequency given does
not include compensations,
such as slip compensation.
The unit is set in o1-03.
10 V: Max. frequency
(0 to ± 10 V possible)
0.01
Hz
AAAA53H
U1-21 ASR input
Monitors the input to the
speed control loop.
The maximum frequency
corresponds to 100%.
10 V: Max. frequency
(0 to ± 10 V possible)
0.01
%
No A No A 54H
U1-22 ASR output
Monitors the output from
the speed control loop.
The motor rated secondary
current corresponds to
100%.
10 V:Motor rated secondary
current)
(0 to ± 10 V possible)
0.01
%
No A No A 55H
U1-24
PID feed-
back value
Monitors the feedback
value when PID control is
used.
The input for the max. fre-
quency corresponds to
100%.
10 V: Max. frequency
(0 to ± 10 V possible)
0.01
%
AAAA57H
U1-26
Output volt-
age refer-
ence (Vq)
Monitors the Inverter inter-
nal voltage reference for
motor secondary current
control.
10 V: 200 VAC (400 VAC)
(0 to ± 10 V possible)
0.1
V
No No A A 59H
U1-27
Output volt-
age refer-
ence (Vd)
Monitors the Inverter inter-
nal voltage reference for
motor excitation current
control.
10 V: 200 VAC (400 VAC)
(0 to ± 10 V possible)
0.1
V
No No A A 5AH
U1-28
Software
No. (CPU)
(Manufacturer’s CPU soft-
ware No.)
(Cannot be output.) - A A A A 5BH
Con-
stant
Number
Name Description
Output Signal Level Dur-
ing Multi-Function Analog
Output
Min.
Unit
Control Methods
MEMO
BUS
Regis-
ter
V/f
V/f
with
PG
Open
Loop
Vec-
tor
Flux
Vec-
tor
