Yealink MVC940 Deployment Guide

| Basic Settings of Teams Room Systems | 57
3. Under the tab of Peripherals, select Yealink UVC30 Camera from the drop-down menu of Yealink
UVC30 Camera.
Note: Tap Preview and pan or tilt the content camera according to the preview to make sure
that the video image of the content camera is contained in the preview.
4. Enable Content enhancements(recommended).
5. Tap Save and exit.
Sharing the Content on the Whiteboard with Remote Participants
In a conference, if you want to share the content on the whiteboard to the remote participants, you can
switch the video image to the content camera and send the content to the remote participants.
Procedure
On the Conference Control page, tap and switch to the content camera.
If there is content sharing now, tap and then select the content camera.
Adjusting the Camera Layout of the MVC940/MVC900/MVC900
Ⅱ
System
After enabling the camera layout feature for Camera-Hub on the Yealink RoomConnect, you can adjust the
camera layout of the MVC940/MVC900/MVC900
Ⅱ
system.
About this task
The following camera layout are supported:
• Fullscreen: the selected camera is displayed in full screen.
• Division: every camera is given equal prominence in equal-sized panes.
• Surround: the assigned camera is given prominence in the largest pane, and other cameras are
displayed in a strip beside the assigned camera.
For more information on how to enable the camera layout feature for Camera-Hub on Yealink
RoomConnect, refer to Yealink RoomConnect User Guide.

Yealink MVC940 Specifications

General

Reset slot	Yes
USB connector type	USB Type-A, USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
HDMI output ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Display diagonal	11.6 \
Touchscreen type	Capacitive
Megapixel	- MP
Camera type	Single camera
Sensor type	CMOS
Optical zoom	12 x
Image sensor size	- \
Diagonal field of view	80 °
Vertical field of view	45 °
Horizontal field of view	73 °
Harmonized System (HS) code	85176990
Pan range	0 - 200 °
Product type	Group video conferencing system
Product color	Black
Tilt angle range	0 - 130 °
Bluetooth version	5.2
Number of cameras	2
Number of persons	- person(s)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Processor family	Intel® Core™ i5
Computer system type	Mini PC
Operating system installed	Windows 10 IoT Enterprise
Internal memory	8192 MB
Storage media type	SSD
Total storage capacity	128 GB
Maximum video resolution	3840 x 2160 pixels
Telepresence	-
Trusted Platform Module (TPM) version	2.0
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Interface module RJ-45 ports quantity	7

Weight and Dimensions

Weight	12100 g
Package depth	413 mm
Package width	935 mm
Package height	312 mm
Package weight	13800 g
