Yealink MVC940 Deployment Guide

| Basic Settings of Teams Room Systems | 61
Wired Content Sharing
For MVC series, you can use MShare for wired content sharing after it is connected to the PC via Mini-DP/
HDMI. For MVC
Ⅱ
series, you can use MTouch
Ⅱ
for wired content sharing after it is connected to the PC
via USB-C/HDMI.
Procedure
Do one of the following:
• On the idle screen, tap Present.
• During a meeting, tap Present to start content sharing with the participants.
Wireless Content Sharing
You can use Yealink WPP20 wireless presentation pod for wireless content sharing. For MVC system, you
should pair the WPP20 with the MShare and connect it to the computer before content sharing. For MVC
Ⅱ
system, you should pair the WPP20 with the MTouch
Ⅱ
and connect it to the computer before content
sharing.
Note: Only the duplicate display mode is applicable to wireless content sharing and the extended
display mode is not applicable when using multiple displays.
Note: For Mac OS, you need to use USB-A to USB-C adapter to connect WPP20.
• Pairing the WPP20 with the MShare
• Pairing the WPP20 with the MTouch
Ⅱ
• Sharing Content via WPP20
• Stopping Sharing Content via WPP20
Pairing the WPP20 with the MShare
Procedure
1. Connect the WPP20 to the USB port of the MShare.
2. Wait for about 3 seconds, and the WPP20 LED indicator glows green.
The WPP20 is paired with the MShare successfully.
Pairing the WPP20 with the MTouch
Ⅱ
Procedure
1. Connect the WPP20 to the USB port of the MTouch
Ⅱ.
2. Wait for about 3 seconds, and the WPP20 LED indicator glows green.
The WPP20 is paired with the MTouch
Ⅱ
successfully.
Sharing Content via WPP20
Before you begin
Make sure the WPP20 has been paired with the MTouch
Ⅱ
MShare.
Procedure
1. Connect the WPP20 wireless presentation pod to your computer.

Yealink MVC940 Specifications

General

Reset slot	Yes
USB connector type	USB Type-A, USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
HDMI output ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Display diagonal	11.6 \
Touchscreen type	Capacitive
Megapixel	- MP
Camera type	Single camera
Sensor type	CMOS
Optical zoom	12 x
Image sensor size	- \
Diagonal field of view	80 °
Vertical field of view	45 °
Horizontal field of view	73 °
Harmonized System (HS) code	85176990
Pan range	0 - 200 °
Product type	Group video conferencing system
Product color	Black
Tilt angle range	0 - 130 °
Bluetooth version	5.2
Number of cameras	2
Number of persons	- person(s)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Processor family	Intel® Core™ i5
Computer system type	Mini PC
Operating system installed	Windows 10 IoT Enterprise
Internal memory	8192 MB
Storage media type	SSD
Total storage capacity	128 GB
Maximum video resolution	3840 x 2160 pixels
Telepresence	-
Trusted Platform Module (TPM) version	2.0
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Interface module RJ-45 ports quantity	7

Weight and Dimensions

Weight	12100 g
Package depth	413 mm
Package width	935 mm
Package height	312 mm
Package weight	13800 g
