User Guide SIP-T20P IP Phone
12
3) Connect the Network and Power:
You have two options for power and network connections. Your system administrator will
advise you which one to use.
AC power
Power over Ethernet (PoE)
AC Power
To connect the AC power:
1. Connect the DC plug on the power adapter to the DC5V port on the phone and
connect the other end of the power adapter into an electrical power outlet.
2. Connect the supplied Ethernet cable between the Internet port on the phone and
the Internet port in your network or switch/hub device port.
Power over Ethernet
Using a regular Ethernet cable, the SIP-T20P IP phone can be powered from a PoE (IEEE
802.3af) compliant switch or hub.

Table of Contents

Other manuals for Yealink SIP-T20P

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yealink SIP-T20P and is the answer not in the manual?

Yealink SIP-T20P Specifications

General IconGeneral
Keypad number of keys31
SpeakerphoneYes
Voice codecsG.711, G.722, G.723.1, G.726
MountingDesk/Wall
Handset typeWired handset
Product typeIP Phone
Product colorBlack
Touchscreen-
Lines quantity2 lines
Phonebook capacity1000 entries
Number of VoIP accounts2
BluetoothNo
Security algorithmsHTTPS, SSL/TLS
AC adapter input voltage100 - 240 V
AC adapter output voltage5 V
Power consumption (typical)2.6 W
Operating relative humidity (H-H)10 - 95 %
Compliance industry standardsIEEE 802.3af
Number of handles included1 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth200 mm
Width185 mm
Height90 mm
Weight770 g
