Yealink SIP-T27P User Manual

User Guide for the SIP-T27P IP Phone
156
The default tag is Empty if it is not configured before.
3. Press the Option soft key, and then press the Edit soft key.
4. Enter the multicast IP address and port number (e.g., 224.5.6.20:10008) in the Address field.
The valid multicast IP addresses range from 224.0.0.0 to 239.255.255.255.
5. Enter the group name in the Label field.
6. Enter the desired channel in the Channel field.
The valid channel ranges from 0 to 30.
7. Press the Save soft key to accept the change or the Back soft key to cancel.
8. Repeat steps 2 to 7, you can add more paging groups.
Paging list is configurable via web user interface at the path Directory->Multicast IP.
To delete a paging group via phone user interface:
1. Press the paging list key when the phone is idle.
2. Press or to select a desired paging group.
3. Press the Option soft key, and then press the Delete soft key.
The LCD screen prompts “Delete selected paging group?”.

Yealink SIP-T27P Specifications

General

Handset type	Wired handset
Product type	IP Phone
Product color	Cappuccino, Black
Backlight keypad	Yes
Volume control	Digital
Base station keys	36
Number of programmable keys	8
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.722, G.726, G.711, G.729, G.711a, G.729A, iLBC, G.729B
Display diagonal	3.66 \
Display resolution	240 x 120 pixels
Networking standards	IEEE 802.1p, IEEE 802.3af, IEEE 802.1x, IEEE 802.1Q
RJ-9 ports quantity	2
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	210 mm
Width	265 mm
Height	170.5 mm
Package depth	225 mm
Package width	300 mm
Package height	118 mm
