Yealink SIP-T27P User Manual

User Guide for the SIP-T27P IP Phone
184
2. Select the desired message and then press the View soft key.
Note
To send a text message:
1. Press Menu->Message->Text Message->New Message.
2. Compose the new text message.
You can press the abc soft key to change the input mode.
3. Press the Send soft key.
4. (Optional.) Press or , or the Switch soft key to select the desired account from the
From field.
5. Enter the number you want to send the message to in the To field.
6. Press the Send soft key to send the message or the Back soft key to cancel.
Sending a text message is configurable via web user interface at the path Features->SMS.
To reply a text message:
1. Press Menu->Message->Text Message->Inbox.
2. Select the desired message and then press the Reply soft key.
3. Compose the new text message. You can press the abc soft key to change the input mode.
4. Press the Send soft key after completing the content.
5. Check the From and To fields, and then press the Send soft key.
If the phone prompts receiving new text messages, you can also press the View soft key to read
the new messages directly.

Yealink SIP-T27P Specifications

General

Handset type	Wired handset
Product type	IP Phone
Product color	Cappuccino, Black
Backlight keypad	Yes
Volume control	Digital
Base station keys	36
Number of programmable keys	8
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.722, G.726, G.711, G.729, G.711a, G.729A, iLBC, G.729B
Display diagonal	3.66 \
Display resolution	240 x 120 pixels
Networking standards	IEEE 802.1p, IEEE 802.3af, IEEE 802.1x, IEEE 802.1Q
RJ-9 ports quantity	2
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	210 mm
Width	265 mm
Height	170.5 mm
Package depth	225 mm
Package width	300 mm
Package height	118 mm
