Yealink SIP-T27P User Manual

Getting Started
17
2) Connect the handset and optional headset
Note
3) Connect the network and power
You have two options for power and network connections. Your system administrator will advise
you which one to use.
 AC power (Optional)
 Power over Ethernet (PoE)
AC Power (Optional)
To connect the AC power:
1. Connect the DC plug on the power adapter to the DC5V port on the phone and connect the
other end of the power adapter into an electrical power outlet.
2. Connect the included or a standard Ethernet cable between the Internet port on the phone
and the one on the wall or switch/hub device port.
Note
The IP phone should be used with Yealink original power adapter (5V/1.2A) only. The use of the
third-party power adapter may cause the damage to the phone.
The EXT port can also be used to connect an expansion module EXP20.
For more information on how to use EHS36 and EXP20, refer to Yealink EHS36 User Guide and
Yealink EXP20 User Guide .

Yealink SIP-T27P Specifications

General

Handset type	Wired handset
Product type	IP Phone
Product color	Cappuccino, Black
Backlight keypad	Yes
Volume control	Digital
Base station keys	36
Number of programmable keys	8
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.722, G.726, G.711, G.729, G.711a, G.729A, iLBC, G.729B
Display diagonal	3.66 \
Display resolution	240 x 120 pixels
Networking standards	IEEE 802.1p, IEEE 802.3af, IEEE 802.1x, IEEE 802.1Q
RJ-9 ports quantity	2
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	210 mm
Width	265 mm
Height	170.5 mm
Package depth	225 mm
Package width	300 mm
Package height	118 mm
