Page #133 background imageLoading...
Page #133 background image
Customizing Your Phone
123
5. Click Add to add the replace rule.
When you enter the number “1” using the keypad and then tap Send, the phone will dial out
“1234” instead.
Note
To edit a replace rule via web user interface:
1. Click on Settings->Dial Plan->Replace Rule.
2. Select the desired replace rule by checking the checkbox.
3. Edit the values in the Prefix and Replace fields.
4. Enter the desired line ID in the Account field or leave it blank.
5. Click Edit to accept the change.
To delete one or more replace rules via web user interface:
1. Click on Settings->Dial Plan->Replace Rule.
2. Select one or more replace rules by checking the checkbox(es).
3. Click Del to delete the replace rule(s).
Dial Now
You can configure one or more dial now rules (up to 100) on your phone. When the dialed
number matches the dial now string, the number will be dialed out automatically. For example, a
dial now rule is configured as "2xx", any entered three-digit string beginning with 2 will then be
dialed out automatically on the phone.
To add a dial now rule via web user interface:
1. Click on Settings->Dial Plan->Dial Now.
2. Enter the desired value (e.g., 2xx) in the Rule field.
3. Enter the desired line ID in the Account field or leave it blank.
The valid values for the Account field can be one or more digits among 1-16. Every two digits
must be separated by a comma. For example, when you enter the value “1, 2” in the Account
field, this replace rule will apply to account 1 and account 2.
If you leave the Account field blank or enter 0, the replace rule will apply to all accounts.

Table of Contents

Other manuals for Yealink SIP-T48S

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yealink SIP-T48S and is the answer not in the manual?

Yealink SIP-T48S Specifications

General IconGeneral
MountingDesk/Wall
Handset typeWired handset
Product typeIP Phone
Product colorBlack
Keypad illuminationYes
Display diagonal7 \
Display resolution800 x 480 pixels
AC adapter input voltage100 - 240 V
AC adapter output current2 A
AC adapter output voltage5 V
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports2
Front cameraNo
Voice codecsCNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity16 lines
Phonebook capacity1000 entries
Number of VoIP accounts16
Dual-Tone Multi-Frequency (DTMF) modesIn-band, Out-of band, SIP info
Keypad number of keys42
Security algorithmsAES
Networking standardsIEEE 802.3af
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Supported network protocolsSIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, HTTPS
Operating temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)10 - 95 %
Cables includedLAN (RJ-45)
Number of handles included1 pc(s)
Harmonized System (HS) code85171800
Weight and Dimensions IconWeight and Dimensions
Depth225 mm
Width266 mm
Height185 mm
Package depth263 mm
Package width324 mm
Package height128 mm
