Getting Started
35
Touch Screen Display
Idle Screen Display
If the phone has successfully started up, the idle screen will be displayed. The following figure is
an example of what is displayed on the touch screen.
No.
Name
Description
1
Status Bar
Displays the phone’s default account, icons and the
time and date.
2
Default Account
The label of the default account is displayed on the
left of the status bar.
If multiple accounts are already registered, tap and
select the desired default account.
For more information, refer to Default Account on
page 119.
Note: You can configure the IP phone not to display
the default account. Contact your system
administrator for more information.
3
Icons
Icons are displayed in the middle of the status bar.
For more information, refer to Icon Instructions on
page 3.
4
Time and Date
The phone’s time and date are displayed on the
right of the status bar.
For more information, refer to Time & Date on page
55.
5
Line Keys (1-11)
The idle screen displays line keys 1-11. The line keys
1-6 on the left and the line keys 7-11 on the right
can be used to activate up to 11 lines.
Various features can be assigned to line keys.
Each line key can display the label and indicate the

Table of Contents
