User Guide for the SIP-T48S IP Phone
52
The default value is 10, you can set to 1-30.
5. Click Confirm to accept the change.
Backlight
Backlight has three options:
Active Level: The intensity of the touch screen when the phone is active. You can change the
intensity of the touch screen. Digits (1-10) represent different intensities. 10 is the highest
intensity.
Inactive Level: The intensity of the touch screen when the phone is inactive. You can select a
low intensity or turn off the backlight.
Backlight Time: The delay time to change the intensity of the touch screen when the phone is
inactive. You can select a desired time to change the intensity or turn on the backlight
permanently.
Always On: Backlight is on permanently.
15s, 30s, 1min, 2min, 5min, 10min or 30min: Backlight is changed when the phone is
inactive after the designated time (in seconds).
You can also change the intensity of the LCD screen of EXP40 connected to the SIP-T48S IP
phone.
To configure the backlight via phone user interface:
1. Tap ->Basic->Display->Backlight.
2. Tap the gray box of the Active Level field, and then select the desired level from the
pull-down list.
3. Tap the gray box of the Inactive Level field, and then select the desired value from the

Table of Contents

Other manuals for Yealink SIP-T48S

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yealink SIP-T48S and is the answer not in the manual?

Yealink SIP-T48S Specifications

General IconGeneral
MountingDesk/Wall
Handset typeWired handset
Product typeIP Phone
Product colorBlack
Keypad illuminationYes
Display diagonal7 \
Display resolution800 x 480 pixels
AC adapter input voltage100 - 240 V
AC adapter output current2 A
AC adapter output voltage5 V
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports2
Front cameraNo
Voice codecsCNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity16 lines
Phonebook capacity1000 entries
Number of VoIP accounts16
Dual-Tone Multi-Frequency (DTMF) modesIn-band, Out-of band, SIP info
Keypad number of keys42
Security algorithmsAES
Networking standardsIEEE 802.3af
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Supported network protocolsSIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, HTTPS
Operating temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)10 - 95 %
Cables includedLAN (RJ-45)
Number of handles included1 pc(s)
Harmonized System (HS) code85171800
Weight and Dimensions IconWeight and Dimensions
Depth225 mm
Width266 mm
Height185 mm
Package depth263 mm
Package width324 mm
Package height128 mm
