Yealink SIP-T48S User Manual

User Guide for the SIP-T48S IP Phone
200
Hot Desking
Hot desking originates from the definition of being the temporary physical occupant of a work
station or surface by a particular employee. A primary motivation for hot desking is cost
reduction. This feature is regularly used in places where not all the employees are in the office at
the same time, or not in the office for very long, which means that actual personal offices would
be often vacant, consuming valuable space and resources.
You can use hot desking on the SIP-T48S IP phone to log out of existing accounts and then log
into a new account. As a result, many users can share the phone resource at different times. To
use this feature, you need to configure a hot desking key in advance.
Note
To configure a hot desking key via phone user interface:
1. Tap More.
2. Tap the desired line key.
3. Tap the gray box of the Type field, and then select Key Event from the pull-down list.
4. Tap the gray box of the Key Type field, and then select Hot Desking from the pull-down
list.
5. (Optional.) Enter the string that will appear on the touch screen in the Label field.
6. Tap the Save soft key to accept the change or to cancel.
Hot desking key is configurable via web user interface at the path Dsskey->Line Key.
Hot desking is not available on all servers. Contact your system administrator for more
information.

Yealink SIP-T48S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Display diagonal	7 \
Display resolution	800 x 480 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Front camera	No
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Keypad number of keys	42
Security algorithms	AES
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, HTTPS
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	225 mm
Width	266 mm
Height	185 mm
Package depth	263 mm
Package width	324 mm
Package height	128 mm
