Yealink SIP-T48S User Manual

User Guide for the SIP-T48S IP Phone
170
To park a call in FAC mode:
1. During a call, tap the Park soft key (You may need to tap the More soft key to see the Park
soft key) or press the call park key (if configured).
- If the call park code is not configured, you need to enter the call park code.
Press , or tap Park.
- If the call park code is configured, the phone will dial the configured call park code
shown as below:
2. Do one of the following:
a) If you want to park the call against the local extension.
1) Press .
If the call is parked successfully, you will hear a voice prompt confirming that the
call is parked.
b) If you want to park the call against desired extension.
1) Enter an extension (e.g., 4606) where you want to park the call.
2) Press or .

Yealink SIP-T48S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Display diagonal	7 \
Display resolution	800 x 480 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Front camera	No
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Keypad number of keys	42
Security algorithms	AES
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, HTTPS
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	225 mm
Width	266 mm
Height	185 mm
Package depth	263 mm
Package width	324 mm
Package height	128 mm
