YOKOGAWA 436101 User Manual

9-22
IM 04P02B01-01E
Reset
Selects whether to reset the TLOG computed value at each interval. The figure below
illustrates the reset operation for sum computation (TLOG.SUM).
Example: TLOG.SUM computation
12 3
ResetReset Reset
Reset: On
Timer timeout
Reset: Off
When reset is ON, the sum value is calculated over each interval. When set to Off, the
sum value from computation start is calculated.
Printout
On: Prints the computed value every interval specified by the timer. Computation
channels set to Off do not apply.
Off: Does not print.
9.12 Setting the Timer Used in TLOG Computation and Periodic Printout
