12-21
IM 04P02B01-01E
Specifications
12
12.7 Dimensional Drawings
(Dimensions before attaching
the mounting bracket)
(Dimensions after attaching
the mounting bracket)
Unit: mm (approx. inch)
Unless otherwise specified, tolerance is ±3%
(however, tolerance is ±0.3 mm when below 10 mm).
39.5
(1.56)
180.5
(7.11)
279.6
(11.01)
180
(7.09)
108
(4.25)
180
(7.09)
108
(4.25)
(0.94)
+1
0
279.6
(11.01)
+1
0
54.6 (2.15)
288 (11.34)
294.6 (11.6)
288 (11.34)
294.6 (11.6)
220 (8.66)
180.5 (7.11)
39.5 (1.56)
9.4 (0.37)
2 to 26
(panel thickness)
7.5 (0.3)
24
Note
When mounting the recorder to a panel, use two brackets, top and bottom or left and right.
