Specifications
12
12.1 Input Specifications
Number of Inputs and Scan Interval on the Pen Model
Item Specifications
Number of inputs 1, 2, 3, or 4
Scan interval 125 ms
Number of Inputs and Scan Interval on the Dot Model
Item Specifications
Number of inputs 6, 12, 18, or 24
Scan interval
Model
100ms
6 dot
12 dot
18 dot
24 dot
2.5 sec
5 sec
10 sec
10 sec
Integration time of
the A/D converter
20ms/16.7ms
1 sec
2.5 sec
2.5 sec
2.5 sec
Input Type
Item Specifications
Input type DC voltage, 1-5V, TC, RTD, DI (ON/OFF input), DC current (by adding an external shunt resistor)
Input Range and Measurable Range
Input Range Type Measurable Range
Volt 20 mV –20.00 to 20.00 mV
60 mV –60.00 to 60.00 mV
200 mV –200.0 to 200.0 mV
2 V –2.000 to 2.000 V
6 V –6.000 to 6.000 V
20 V –20.00 to 20.00 V
50 V –50.00 to 50.00 V
1-5V (0.800 to 1.200 V range) to (4.800 to 5.200 V range)
TC R
1
0.0 to 1760.0 °C 32 to 3200 °F
S
1
0.0 to 1760.0 °C 32 to 3200 °F
B
1
0.0 to 1820.0 °C 32 to 3308 °F
K
1
−200.0 to 1370.0 °C −328 to 2498 °F
E
1
−200.0 to 800.0 °C −328.0 to 1472.0 °F
J
1
−200.0 to 1100.0 °C −328.0 to 2012.0 °F
T
1
−200.0 to 400.0 °C −328.0 to 752.0 °F
N
1
0.0 to 1300.0 °C 32 to 2372 °F
W
2
0.0 to 2315.0 °C 32 to 4199 °F
L
3
−200.0 to 900.0 °C −328.0 to 1652.0 °F
U
3
−200.0 to 400.0 °C −328.0 to 752.0 °F
WRe
4
0.0 to 2400.0 °C 32 to 4352 °F
RTD PT (Pt100)
5
–200.0 to 600.0°C −328.0 to 1112.0 °F
JPT (JPt100)
5
–200.0 to 550.0°C −328.0 to 1022.0 °F
DI Level 0: Less than 2.4 V, 1: Greater than or equal to 2.4 V
Contact 0: Open, 1: Closed
1 R, S, B, K, E, J, T, N: IEC584-1 (1995), DIN IEC584, JIS C1602-1995
2 W: W-5% Rd/W-26% Rd (Hoskins Mfg. Co.), ASTM E988
3 L: Fe-CuNi, DIN43710, U: Cu-CuNi, DIN43710
4 WRe: W-3%Re/W-25%Re (Hoskins Mfg Co.)
5 Pt100: JIS C1604-1997, IEC751-1995, DIN IEC751-1996
JPt100: JIS C1604-1989, JIS C1606-1989
Measurement current: i = 1 mA (Pt100, JPt100)
