12-5
IM 04P02B01-01E
Specifications
12
Printouts (Pen Model)
Item Specifications
Recording pen (color) Plotter pen (purple)
Alarm printout Prints alarm occurrence/release.
Printout contents Occurrence ( )/release ( ) marks, channel No. or tag, alarm type, alarm level, time, printout
buffer overflow mark.
Time printout format Selectable from hour:minute, hour:minute:second, month:day:hour:minute,
month:day:hour:minute:second, and year:month:day:hour:minute:second.
Alarm printout buffer Stores 24 occurrences of alarm information waiting to be printed.
Periodic printout Prints at specified time intervals from the reference time.
Interval Reference time: 00 hour 00 minute to 23 hour 00 minute (1 hour steps, minute fixed)
Auto: Automatically determined from the chart speed.
Manual: Select 10 min, 12 min, 15 min, 20 min, 30 min, 1 hour, 2 hours, 3 hours, 4 hours, 6 hours,
8 hours, 12 hours, or 24 hours.
Mode Selectable from disable periodic printout, print instantaneous values, and print report data (report mode).
Report data: Selectable from the average, minimum, maximum, minimum/maximum/average, sum
value, and instantaneous value.
Printout contents For instantaneous values: Date/Time, offset compensation ON/OFF, channel information
(measured value, alarm status, unit, delta computation ON/OFF, scale,
channel number or tag, recording color), chart speed (with time ticks)
For report data: Report start/end date/time, offset compensation ON/OFF, events, channel
information (value, unit, range change occurrence, scale, recording color), chart
speed (with time ticks)
Message printout Prints preset message strings.
Number of messages 5
Printout contents Time, message (up to 16 characters), printout buffer overflow mark.
Time printout format Selectable from hour:minute, hour:minute:second, month:day:hour:minute,
month:day:hour:minute:second, year:month:day:hour:minute:second, and not print.
Message printout buffer Stores 5 messages waiting to be printed.
Recording start printout Prints at the start of recording.
Printout contents Time and chart speed, printout buffer overflow mark.
Time printout format Selectable from hour:minute, hour:minute:second, month:day:hour:minute,
month:day:hour:minute:second, and year:month:day:hour:minute:second.
New chart speed printout Prints when the chart speed is changed.
Printout contents Chart speed and time, printout buffer overflow mark.
Time printout format Selectable from hour:minute, hour:minute:second, month:day:hour:minute,
month:day:hour:minute:second, and year:month:day:hour:minute:second.
Manual printout Prints the measured values of all channels.
Printout contents Measured values of all channels at that point.
Trend recording is temporarily suspended.
Setting printout (List) Prints the settings of items in Setting mode.
Printout contents Range setting, alarm setting, etc.
Trend recording is temporarily suspended.
Setting printout (Setup) Prints the settings of items in Basic Setting mode.
Printout contents Basic alarm specifications, basic recording specifications, etc.
Trend recording is temporarily suspended.
Items dependent on the chart speed
5 to 9 mm/h
10 to 1500 mm/h
1600 mm/h or higher
Periodic printout
Not printed
Printed
Not printed
Alarm printout
Message printout
New chart speed printout
Printed
Printed
Not printed
Chart speed
10 to 18 mm/h
20 to 36 mm/h
40 to 72 mm/h
75 to 135 mm/h
150 to 180 mm/h
200 to 320 mm/h
350 to 1500 mm/h
Periodic printout interval
8 hours
4 hours
2 hours
1 hour
30 minutes
20 minutes
10 minutes
Chart speed
Date printout format Select the printout format of the date from Y/M/D, M/D/Y, D/M/Y, D.M.Y, and M.D.Y. The format
applies to the date printout of all printout items.
