4-19
IM 04P01B01-17E
Commands
4
VP Turns Start printout/End printout
ON/OFF (/BT1 option).
Syntax VP p1,p2,p3,p4<terminator>
p1 Mode selection
START Start printou
END End printout
START2 Start printout 2
END2 End printout 2
p2 Batch name printout ON/OFF (ON, OFF)
p3 Chart speed printout ON/OFF (ON, OFF)
p4 Date/time printout ON/OFF (ON, OFF)
Query VP[ p1]?
Example Turn the Start printout batch name (batch
number and lot number) ON, chart speed OFF,
and date/time ON.
VP START,ON,OFF,ON
Description • Valid with the header printout (/BT1 option)
when set to use Start printout/End printout
(see the UE command).
• Start printout 2 and End printout 2 valid when
set to use Start printout 2 and End printout 2
(see the UE command).
VA Sets the Start printout/End
printout action (/BT1 option).
When setting Start printout
Syntax VA p1,p2<terminator>
p1 Mode selection
START Start printout
START2 Start printout 2
p2 Feed amount before Start printout (0-50)
[mm]
Query VA[ p1]?
Example Set feed amount before Start printout to 10 mm.
VA START,10
Description • Valid with the header printout (/BT1 option)
when set to use Start printout/End printout
(see the UE command).
• Start printout 2 valid when set to use Start
printout 2 and End printout 2 (see the UE
command).
When setting End printout
Syntax VA p1,p2,p3,p4,p5<terminator>
p1 Mode selection
END End printout
END2 End printout 2
p2 Feed amount after End printout (0-50) [mm]
p3 Lot number automatic updating ON/OFF
(ON, OFF)
p4 Pen offset compensating recording ejection
ON/OFF (ON, OFF)
p5 Select chart speed when ejecting pen offset
compensating record.
C.SPEED Chart speed setting
450mm/h Fixed to 450 mm/h
Query VA[ p1]?
Example Set feed amount after End printout to 10 mm.
VA END,10
Description • Valid with the header printout (/BT1 option)
when set to use Start printout/End printout
(see the UE command).
• End printout 2 valid when set to use Start
printout 2 and End printout 2 (see the UE
command).
• P3 valid when lot number is set to 4 or 6 digits
(see the UE command).
• P4 valid when POC is set to ON with the pen
model (see the UE command).
• P5 is valid when p4 is ON.
VM Sets the message format
(/BT1 option).
Syntax VM p1,p2<terminator>
p1 Message number (1-5)
p2 Message format setting
(µR10000: up to 35 chars., µR20000: up to
69 chars.)
H:M Hours:minutes (5 characters)
H:M:S Hours:minutes:seconds
(8 characters)
M/D H:M Month/day hours:minutes
(11 characters)
M/D H:M:S Month/day hours:minutes:
seconds (14 characters)
D/M H:M Day/month hours:minutes
(11 characters)
D/M H:M:S Day/month hours:minutes:
seconds (14 characters)
D.M H:M Day.month hours:minutes
(11 characters)
D.M H:M:S Day.month hours:minutes:
seconds (14 characters)
M.D H:M Month.day hours:minutes
(12 characters)
M.D H:M:S Month.day hours:minutes:
seconds (15 characters)
Y/M/D H:M:S Year/month/day hours:
minutes:seconds
(19 characters)
M/D/Y H:M:S Month/day/year:hours:
minutes:seconds
(19 characters)
D/M/Y H:M:S Day/month/year hours:
minutes:seconds
(19 characters)
D.M.Y H:M:S Day.month.year hours:
minutes:seconds
(19 characters)
M.D.Y H:M:S Month/day/year hours:
minutes:seconds
(20 characters)
4.4 Setting Commands
