4-10
IM 04P02B01-01E
Setup Item Pen/Dot Selectable Range or Selections Default Value
Math > Unit > Unit - 6 characters or less Blank
Math > Constant > No. - K01 to K30 K01
Math > Alarm > CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
1A/1B/1C/1D/1E/1F/1G/1J/1K/1M/1N/1P
Math > Alarm > Level - 1/2/3/4 1
Math > Alarm > Alarm - On/Off Off
Math > Alarm > Type - H/L (*/T/t) -
Math > Alarm > Value - –9999999 to 99999999 excluding the decimal -
Math > Alarm > Relay - On/Off Off
Math > Alarm > Relay No. - I01 to I06 101
Math > TLOG > CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
1A/1B/1C/1D/1E/1F/1G/1J/1K/1M/1N/1P
Math > TLOG > Timer No. - Periodic/1/2 Periodic
Math > TLOG > SUM scale - Off, /s, /min, /h, /day Off
Math > Aux > Zone > CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
1A/1B/1C/1D/1E/1F/1G/1J/1K/1M/1N/1P
Math > Aux > Zone > Left, Right - Within the recording span range (mm) Left: 0, Right: 180
*Math > Aux > Partial > CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
1A/1B/1C/1D/1E/1F/1G/1J/1K/1M/1N/1P
*Math > Aux > Partial > Partial - On/Off Off
*Math > Aux > Partial > Expand - 1 to 99% 50
*Math > Aux > Partial > Bound - Within the recording span range -
Math > Aux > Print out > CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
1A/1B/1C/1D/1E/1F/1G/1J/1K/1M/1N/1P
Math > Aux > Print out > Trend Dot Model On/Off On
Math > Aux > Print out > Periodic - On/Off On
Math > Aux > Tag > CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
1A/1B/1C/1D/1E/1F/1G/1J/1K/1M/1N/1P
Math > Aux > Tag > Tag - 7 characters or less 0A to 1P
*Math > Aux > Alm delay T > CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
1A/1B/1C/1D/1E/1F/1G/1J/1K/1M/1N/1P
*Math > Aux > Alm delay T > Duration - 0 to 3600s 10s
Setup Items in Basic Setting Mode and Their Default Values
Setup Item Pen/Dot Selectable Range or Selections Default Value
Alarm > Diagnosis - On/Off Off
Alarm > Reflash - On/Off Off
Alarm > AND - None/I01/I01-I02/I01-I03/I01-I04/I01-I05/ None
I01-I06/I01-I11/I01-I12/I01-I13/I01-I14/
I01-I15/I01-I16/I01-I21/I01-I22/I01-I23/
I01-I24/I01-I25/I01-I26/I01-I31/I01-I32/
I01-I33/I01-I34/I01-I35/I01-I36
Alarm > Act - Energize/De_energize Energize
Alarm > Behavior - Nonhold/Hold Nonhold
Alarm > Indicator - Nonhold/Hold Nonhold
Alarm > Increase - 01 to 15 01
Alarm > Decrease - 01 to 15 01
Alarm > Hysteresis - Off/0.1% to 1.0% 0.5%
Alarm > M_Hysteresis - Off/0.1% to 1.0% Off
A/D > Integrate - Auto/50Hz/60Hz/100ms Auto
Burnout > CH - 01 to 24 01
Burnout > Burnout - Off/Up/Down Off
RJC > CH - 01 to 24 01
RJC > RJC - Internal/External Internal
RJC > RJC > Volt - –20000 to 20000 µV0 µV
Color > Channel Dot Model 01 to 24 01, 07, 13, 19: Purple
Color > Color Dot Model Purple/Red/Green/Blue/Brown/Black 02, 08, 14, 20: Red
03, 09, 15, 21: Green
04, 10, 16, 22: Blue
05, 11, 17, 23: Brown
06, 12, 18, 24: Black
POC > POC Pen Model On/Off Off
4.3 Menu Structure, Settings, and List of Default Values
To Next Page
