Common Operations for Setting Functions and Setup Guide
4
Setup Item Pen/Dot Selectable Range or Selections Default Value
Print > CH/Tag - CH/Tag CH
Print > Channel Dot Model On/Off On
Print > Alarm - On1/On2/Off On1
Print > Record On - On/Off Off
Print > Chart speed - On/Off On
Print > Scale - On/Off On
Print > Pen color Pen Model On/Off On
Print1 > Periodic - Auto/Manual Auto
Print1 > Ref. Time - Hour 0 to 23 (1 hour steps) 00:00
Print1 > Interval - 10min/15min/20min/30min/1h/2h/3h/4h 1h
/6h/8h/12h/24h
Print1 > Mode - Inst/Report/Off Inst
Print2 > CH - 01 to 24 01
Print2 > Mode - AVE/MIX/SUM/MIN/MAX/INST AVE
Print2 > SUM scale - Off, /s, /min, /h, /day Off
Bar graph > CH - 01 to 24 01
Bar graph > Graph - Normal/Center Normal
Keylock > Keylock - Not/Use Not
Keylock > Password - Numbers and spaces within 4 digits Blank
Keylock > RCD - Free/Lock Free
Keylock > Feed - Free/Lock Free
Keylock > Menu - Free/Lock Free
Keylock > Disp Menu - Free/Lock Free
Keylock > Alarm ACK - Free/Lock Free
Keylock > Math - Free/Lock Free
Keylock > Print out - Free/Lock Free
Keylock > Message - Free/Lock Free
Keylock > Buffer clear - Free/Lock Free
Keylock > Periodic - Free/Lock Free
Keylock > Pen exchange Pen Model Free/Lock Free
Keylock > Ribbon exchange Dot Model Free/Lock Free
Moving_AVE > Moving_AVE Dot Model Not/Use Not
Filter > Filter Pen Model Not/Use Not
Partial > Partial - Not/Use Not
Language > Lang - English/Japanese English
Date format > Type - Y/M/D M/D/Y D/M/Y D.M.Y M.D.Y M.D.Y
Temperature > Temp - C/F C
Personalize > Add function > Bias - Not/Use Not
Personalize > Add function > SQRT low-cut - Not/Use Use
Personalize > Add function > 1-5V low-cut - Not/Use Not
Personalize > Add function > Alarm delay - Not/Use Not
Personalize > Time print > Alarm - HH:MM, HH:MM:SS, M/D H:M, M/D H:M:S, HH:MM
YMD H:M:S
Personalize > Time print > Message - HH:MM, HH:MM:SS, M/D H:M, M/D H:M:S, HH:MM
YMD H:M:S, None
Personalize > Time print > RCD On - HH:MM, HH:MM:SS, M/D H:M, M/D H:M:S, HH:MM
YMD H:M:S
Personalize > Time print > C.Speed - HH:MM, HH:MM:SS, M/D H:M, M/D H:M:S, HH:MM
YMD H:M:S
Setting initialization
Initialize > Mode - Setup+Set/Set Setup+Set
Initialize > Mode > Are you sure? - No/Yes No
Remote control function (/R1 option)
Remote > Remote No. - 1/2/3/4/5 1
Remote > Remote No. > No. - Record On Off /Chart speed/Time adjust/ Record On/Off
Math start stop/Math reset/Manual print/
Alarm ACK/Message1/Message2/Message3/
Message4/Message5/None
4.3 Menu Structure, Settings, and List of Default Values
