YOKOGAWA 436101 User Manual

4-12
IM 04P02B01-01E
Computation function (/M1 option)
Setup Item Pen/Dot Selectable Range or Selections Default Value
Math > Timer (TLOG) > Timer No. - 1/2 1
Math > Timer (TLOG) > Mode - Off/Relative/Absolute Absolute
Math > Timer (TLOG) > Interval (Relative) - 10 min to 24 h (1 min steps) 01:00
Math > Timer (TLOG) > Interval (Absolute) - 10min/12min/15min/20min/30min/1h/2h/3h 1h
/4h/6h/8h/12h/24h
Math > Timer (TLOG) > Ref. Time - Hour 0 to 23 (1 hour steps) 00:00
Math > Timer (TLOG) > Reset - On/Off On
Math > Timer (TLOG) > Print - On/Off On
Math > Color > Channel Dot Model 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
1A/1B/1C/1D/1E/1F/1G/1J/1K/1M/1N/1P
Math > Color > Color Dot Model Purple/Red/Green/Blue/Brown/Black Purple: 0A/0G/1A/1G
Red: 0B/0J/1B/1J
Green: 0C/0K/1C/1K
Blue: 0D/0M/1D/1M
Brown: 0E/0N/1E/1N
Black: 0F/0P/1F/1P
Math > Output pen > Pen ← CH Pen Model Pen: 1 to 4, Channel: 01 to 04/0A to 0J 1pen: 01, 2pen: 02,
3pen: 03, 4pen: 04,
Math > Print2 > CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
1A/1B/1C/1D/1E/1F/1G/1J/1K/1M/1N/1P
Math > Print2 > Mode - AVE/MIX/SUM/MIN/MAX/INST AVE
Math > Print2 > SUM scale - Off, /s, /min, /h, /day Off
Math > Bar graph > CH - 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P 0A
1A/1B/1C/1D/1E/1F/1G/1J/1K/1M/1N/1P
Math > Bar graph > Graph - Normal/Center Normal
Math > Error data > Error - +Over/–Over +Over
Math > Error data > Over - Skip/Limit Skip
RS-422A/485 communication interface function (/C3 option).
Setup Item Pen/Dot Selectable Range or Selections Default Value
RS-422/485 > Address - 1 to 32 1
RS-422/485 > Baud rate - 1200/2400/4800/9600/19200/38400 9600
RS-422/485 > Data length - 7/8 8
RS-422/485 > parity - Odd/Even/None Even
RS-422/485 > Protocol - NORMAL/MODBUS NORMAL
Ethernet communication interface function (/C7 option)
Setup Item Pen/Dot Selectable Range or Selections Default Value
Ethernet > Host > Host - 64 characters or less Blank
Ethernet > Host > Domain - 64 characters or less Blank
Ethernet > Local IP > A - IP address 0.0.0.0
Ethernet > Local IP > M - IP address (Subnet mask) 0.0.0.0
Ethernet > Local IP > G - IP address (Default gateway) 0.0.0.0
Ethernet > DNS > DNS - On/Off Off
Ethernet > DNS > P - IP address (Primary DNS sever) 0.0.0.0
Ethernet > DNS > S - IP address (Secondary DNS sever) 0.0.0.0
Ethernet > DNS > Suffix_P - Primary domain suffix Blank
Ethernet > DNS > Suffix_S - Secondary domain suffix Blank
Ethernet > Login > Login - Use/Not Not
Ethernet > LoginSet > Level - Admin/User1 to User6 Admin
Ethernet > LoginSet > Register - On/Off Admin and User1
are On
Ethernet > LoginSet > User - 16 characters or less Admin: admin
User1 to 6: user1 to
user6
Ethernet > LoginSet > Password - 4 characters or less Administrator: 0
User1 to 6: 1 to 6
Ethernet > Timeout > Timeout - On/Off Off
Ethernet > Timeout > Duration - 1 to 120 min 1 min
Ethernet > K. Alive > Keep alive - On/Off On
4.3 Menu Structure, Settings, and List of Default Values
