YOKOGAWA AXFA14C User Manual

<8. Parameter Summary>
65
IM 01E20A01-01EN
R/W (*3)
Parameter No.
(BRAIN protocol)
Data (*4)
Device setup
Detailed Setup Function Set Status Function SO1 Function (*1) W F10 u/d
PV SO2 Function (*1) W F11 u/d
PV AO SI1 Function (*1) W F12 u/d
PV Span SI2 Function (*1) W F13 u/d
SO1/2 Active Mode (*1) W F14 u/d
SI1/2 Active Mode (*1) W F15 u/d
DO Function (*2) W F20 u/d
DIO Function (*2) W F21 u/d
DO Active Mode (*2) W F22 u/d
DIO Active Mode (*2) W F23 u/d
Forward Span2 W F30 u/d
Forward Span3 W F31 u/d
Forward Span4 W F32 u/d
Reverse Span1 W F33 u/d
Reverse Span2 W F34 u/d
Reverse Span3 (*1) W F35 u/d
Reverse Span4 (*1) W F36 u/d
Auto Range Hys W F40 u/d
Bi Direction Hys W F41 u/d
Alarm
Low Alarm W G10 u/d
High Alarm W G11 u/d
Low Low Alarm W G12 u/d
High High Alarm W G13 u/d
H/L Alarm Hys W G14 u/d
Alm Out Act Mode (*1) W G20 u/d
4-20 Alarm Out W G21 u/d
4-20 Burn Out R G22 -
Alm-Setting W G30 u/d
Alm-Sig Over W G31 u/d
Alm-Emp Pipe W G32 u/d
Alm-HH/LL W G33 u/d
Alm-Adhesion W G34 u/d
Alm Record
Operation Time R G40 P
Alm Record1 R G41 P
Alm Record Time1 R G42 P
Alm Record2 R G43 P
Alm Record Time2 R G44 P
Alm Record3 R G45 P
Alm Record Time3 R G46 P
Alm Record4 R G47 P
Alm Record Time4 R G48 P
Display Set
Display Select1 W H10/B40 u/d
Display Select2 W H11/B41 u/d
Display Select3 W H12/B42 u/d
Display Cycle W H20 u/d
Language W H30/B10 u/d
Aux
4-20mA Low Cut W J10 u/d
4-20mA Low Lmt W J11 u/d
4-20mA High Lmt W J12 u/d
Flow Direction W J20 u/d
Rate Limit W J21 -
Dead Time W J22 -
Pulsing Flow W J23 -
T/P Damp Select W J24 -
Power Synch W J30 -
Power Frequency R/W J31 P
Memo 1 W J40 -
Memo 2 W J41 -
Memo 3 W J42 -
Software Rev No R J50 -
HART output
Poll addr W - -
Num req preams R - -
Burst mode W - -
Burst option
PV W - -
% range/current W - -
Process vars/crnt W - -
Device info
Field device info Manufacturer R - -
Tag W - u/d
Descriptor W - u/d
Message W - u/d
Date W - u/d
Dev id R - -
Write protect R - P
Revision #’s
Universal rev R - -
Fld dev rev R - -
Software rev R - -
Modelspecic
Use W - -
Lining W - -
Electrode Material W - -
Electrode Struct W - -
Grounding Ring W - -
Process Connect W - -
Lay Length W - -
Electrical Conn W - -
Sensor Serial No W - -
Review
Review1 R - -
Review2 R - -
Review3 R - -
Review4 R - -
Hot key
PV Span W B23/C42 u/d
Wrt Protect Menu
Write protect R P20 P
Enable Wrt 10min W P21 -
New Password W P22 -
Software Seal R P23 -
*1 : Applicable for AXFA11 Remote Converter.
*2 : Applicable for AXF Integral Flowmeter and AXFA14 Remote Converter.
*3 : R/W : R = Read only, W = Read and Write
*4 : Data Renewing
P : Periodic Data Renewing
u/d : Discretionary Renewing
– : Others (Method etc...)
Parameter Summary
