YOKOGAWA DL350 Getting Started Guide

App-2
IM DL35 O -03EN
When Sample Rate Is 100MS/s Maximum
When the Record Length Is 10 k, 25 k, 50 k, 100 k, 250 kpoint
Time/div
Record length
10 k 25 k 50 k 100 k 250 k
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
1 µs 100 M 1.0 k 100 M 1.0 k 100 M 1.0 k 100 M 1.0 k 100 M 1.0 k
2 µs 100 M 2.0 k 100 M 2.0 k 100 M 2.0 k 100 M 2.0 k 100 M 2.0 k
5 µs 100 M 5.0 k 100 M 5.0 k 100 M 5.0 k 100 M 5.0 k 100 M 5.0 k
10 µs 100 M 10.0 k 100 M 10.0 k 100 M 10.0 k 100 M 10.0 k 100 M 10.0 k
20 µs 50 M 10.0 k 100 M 20.0 k 100 M 20.0 k 100 M 20.0 k 100 M 20.0 k
50 µs 20 M 10.0 k 50 M 25.0 k 100 M 50.0 k 100 M 50.0 k 100 M 50.0 k
100 µs 10 M 10.0 k 20 M 20.0 k 50 M 50.0 k 100 M 100.0 k 100 M 100.0 k
200 µs 5 M 10.0 k 10 M 20.0 k 20 M 40.0 k 50 M 100.0 k 100 M 200.0 k
500 µs 2 M 10.0 k 5 M 25.0 k 10 M 50.0 k 20 M 100.0 k 50 M 250.0 k
1 ms 1 M 10.0 k 2 M 20.0 k 5 M 50.0 k 10 M 100.0 k 20 M 200.0 k
2 ms 500 k 10.0 k 1 M 20.0 k 2 M 40.0 k 5 M 100.0 k 10 M 200.0 k
5 ms 200 k 10.0 k 500 k 25.0 k 1 M 50.0 k 2 M 100.0 k 5 M 250.0 k
10 ms 100 k 10.0 k 200 k 20.0 k 500 k 50.0 k 1 M 100.0 k 2 M 200.0 k
20 ms 50 k 10.0 k 100 k 20.0 k 200 k 40.0 k 500 k 100.0 k 1 M 200.0 k
50 ms 20 k 10.0 k 50 k 25.0 k 100 k 50.0 k 200 k 100.0 k 500 k 250.0 k
100 ms 10 k 10.0 k 20 k 20.0 k 50 k 50.0 k 100 k 100.0 k 200 k 200.0 k
200 ms 5 k 10.0 k 10 k 20.0 k 20 k 40.0 k 50 k 100.0 k 100 k 200.0 k
500 ms 2 k 10.0 k 5 k 25.0 k 10 k 50.0 k 20 k 100.0 k 50 k 250.0 k
1 s 1 k 10.0 k 2 k 20.0 k 5 k 50.0 k 10 k 100.0 k 20 k 200.0 k
2 s 500 10.0 k 1 k 20.0 k 2 k 40.0 k 5 k 100.0 k 10 k 200.0 k
3 s 200 6.0 k 500 15.0 k 1 k 30.0 k 2 k 60.0 k 5 k 150.0 k
4 s 200 8.0 k 500 20.0 k 1 k 40.0 k 2 k 80.0 k 5 k 200.0 k
5 s 200 10.0 k 500 25.0 k 1 k 50.0 k 2 k 100.0 k 5 k 250.0 k
6 s 100 6.0 k 200 12.0 k 500 30.0 k 1 k 60.0 k 2 k 120.0 k
10 s 100 10.0 k 200 20.0 k 500 50.0 k 1 k 100.0 k 2 k 200.0 k
20 s 50 10.0 k 100 20.0 k 200 40.0 k 500 100.0 k 1 k 200.0 k
30 s 20 6.0 k 50 15.0 k 100 30.0 k 200 60.0 k 500 150.0 k
1 min 10 6.0 k 20 12.0 k 50 30.0 k 100 60.0 k 200 120.0 k
2 min 5 6.0 k 20 24.0 k 20 24.0 k 50 60.0 k 200 240.0 k
3 min 5 9.0 k 10 18.0 k 20 36.0 k 50 90.0 k 100 180.0 k
4 min – – 10 24.0 k 20 48.0 k 20 48.0 k 100 240.0 k
5 min – – 5 15.0 k 10 30.0 k 20 60.0 k 50 150.0 k
6 min – – 5 18.0 k 10
36.0 k 20 72.0 k 50 180.0 k
10 min – – – – 5 30.0 k 10 60.0 k 20 120.0 k
12 min – – – – 5 36.0 k 10 72.0 k 20 144.0 k
30 min – – – – – – 5 90.0 k 10 180.0 k
1 hour – – – – – – – – 5 180.0 k
2 hour – – – – – – – – – –
3 hour – – – – – – – – – –
4 hour – – – – – – – – – –
5 hour – – – – – – – – – –
6 hour – – – – – – – – – –
8 hour – – – – – – – – – –
10 hour – – – – – – – – – –
12 hour – – – – – – – – – –
1 day – – – – – – – – – –
2 day – – – – – – – – – –
3 day – – – – – – – – – –
4 day – – – – – – – – – –
5 day – – – – – – – – – –
Appendix 1 Relationship between the Time Scale, Record Length, and Sample Rate
