YOKOGAWA DL350 Getting Started Guide

App-3
IM DL35 O -03EN
Appendix
1
2
3
4
5
6
App
Index
When the Record Length Is 500 k, 1 M, 2.5 M, 5 M, 10 Mkpoint
Time/div
Record length
500 k 1 M 2.5 M 5 M 10 M
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
Sample
Rate
(S/s)
Actual
record
length
(Point)
1 µs 100 M 1.0 k 100 M 1.0 k 100 M 1.0 k 100 M 1.0 k 100 M 1.0 k
2 µs 100 M 2.0 k 100 M 2.0 k 100 M 2.0 k 100 M 2.0 k 100 M 2.0 k
5 µs 100 M 5.0 k 100 M 5.0 k 100 M 5.0 k 100 M 5.0 k 100 M 5.0 k
10 µs 100 M 10.0 k 100 M 10.0 k 100 M 10.0 k 100 M 10.0 k 100 M 10.0 k
20 µs 100 M 20.0 k 100 M 20.0 k 100 M 20.0 k 100 M 20.0 k 100 M 20.0 k
50 µs 100 M 50.0 k 100 M 50.0 k 100 M 50.0 k 100 M 50.0 k 100 M 50.0 k
100 µs 100 M 100.0 k 100 M 100.0 k 100 M 100.0 k 100 M 100.0 k 100 M 100.0 k
200 µs 100 M 200.0 k 100 M 200.0 k 100 M 200.0 k 100 M 200.0 k 100 M 200.0 k
500 µs 100 M 500.0 k 100 M 500.0 k 100 M 500.0 k 100 M 500.0 k 100 M 500.0 k
1 ms 50 M 500.0 k 100 M 1.0 M 100 M 1.0 M 100 M 1.0 M 100 M 1.0 M
2 ms 20 M 400.0 k 50 M 1.0 M 100 M 2.0 M 100 M 2.0 M 100 M 2.0 M
5 ms 10 M 500.0 k 20 M 1.0 M 50 M 2.5 M 100 M 5.0 M 100 M 5.0 M
10 ms 5 M 500.0 k 10 M 1.0 M 20 M 2.0 M 50 M 5.0 M 100 M 10.0 M
20 ms 2 M 400.0 k 5 M 1.0 M 10 M 2.0 M 20 M 4.0 M 50 M 10.0 M
50 ms 1 M 500.0 k 2 M 1.0 M 5 M 2.5 M 10 M 5.0 M 20 M 10.0 M
100 ms 500 k 500.0 k 1 M 1.0 M 2 M 2.0 M 5 M 5.0 M 10 M 10.0 M
200 ms 200 k 400.0 k 500 k 1.0 M 1 M 2.0 M 2 M 4.0 M 5 M 10.0 M
500 ms 100 k 500.0 k 200 k 1.0 M 500 k 2.5 M 1 M 5.0 M 2 M 10.0 M
1 s 50 k 500.0 k 100 k 1.0 M 200 k 2.0 M 500 k 5.0 M 1 M 10.0 M
2 s 20 k 400.0 k 50 k 1.0 M 100 k 2.0 M 200 k 4.0 M 500 k 10.0 M
3 s 10 k 300.0 k 20 k 600.0 k 50 k 1.5 M 100 k 3.0 M 200 k 6.0 M
4 s 10 k 400.0 k 20 k 800.0 k 50 k 2.0 M 100 k 4.0 M 200 k 8.0 M
5 s 10 k 500.0 k 20 k 1.0 M 50 k 2.5 M 100 k 5.0 M 200 k 10.0 M
6 s 5 k 300.0 k 10 k 600.0 k 20 k 1.2 M 50 k 3.0 M 100 k 6.0 M
10 s 5 k 500.0 k 10 k 1.0 M 20 k 2.0 M 50 k 5.0 M 100 k 10.0 M
20 s 2 k 400.0 k 5 k 1.0 M 10 k 2.0 M 20 k 4.0 M 50 k 10.0 M
30 s 1 k 300.0 k 2 k 600.0 k 5 k 1.5 M 10 k 3.0 M 20 k 6.0 M
1 min 500 300.0 k 1 k 600.0 k 2 k 1.2 M 5 k 3.0 M 10 k 6.0 M
2 min 200 240.0 k 500 600.0 k 2 k 2.4 M 2 k 2.4 M 5 k 6.0 M
3 min 200 360.0 k 500 900.0 k 1 k 1.8 M 2 k 3.6 M 5 k 9.0 M
4 min 200 480.0 k 200 480.0 k 1 k 2.4 M 2 k 4.8 M 2 k 4.8 M
5 min 100 300.0 k 200 600.0 k 500 1.5 M 1 k 3.0 M 2 k 6.0 M
6 min 100 360.0 k 200 720.0 k 500
1.8 M 1 k 3.6 M 2 k 7.2 M
10 min 50 300.0 k 100 600.0 k 200 1.2 M 500 3.0 M 1 k 6.0 M
12 min 50 360.0 k 100 720.0 k 200 1.4 M 500 3.6 M 1 k 7.2 M
30 min 20 360.0 k 50 900.0 k 100 1.8 M 200 3.6 M 500 9.0 M
1 hour 10 360.0 k 20 720.0 k 50 1.8 M 100 3.6 M 200 7.2 M
2 hour 5 360.0 k 10 720.0 k 20 1.4 M 50 3.6 M 100 7.2 M
3 hour – – 5 540.0 k 20 2.1 M 20 2.1 M 50 5.4 M
4 hour – – 5 720.0 k 10 1.4 M 20 2.8 M 50 7.2 M
5 hour – – 5 900.0 k 10 1.8 M 20 3.6 M 50 9.0 M
6 hour – – – – 10 2.1 M 20 4.3 M 20 4.3 M
8 hour – – – – 5 1.4 M 10 2.8 M 20 5.7 M
10 hour – – – – 5 1.8 M 10 3.6 M 20 7.2 M
12 hour – – – – 5 2.1 M 10 4.3 M 20 8.6 M
1 day – – – – – – 5 4.3 M 10 8.6 M
2 day – – – – – – – – 5 8.6 M
3 day – – – – – – – – – –
4 day – – – – – – – – – –
5 day – – – – – – – – – –
Appendix 1 Relationship between the Time Scale, Record Length, and Sample Rate
