YOKOGAWA DL350 Getting Started Guide

App-16
IM DL35 O -03EN
CAN Bus Monitor Module, CAN & LIN Bus Monitor Module, and
SENT Monitor Module
Rate at Which Data Is Written to the Acquisition Memory
Number of Sub Channels Used 1 2 3 or 4 5 to 8 9 to 16 17 to 32 33 to 60
Sub Channel Sample Rate
(Data Update Rate)
100 k 100 k 100 k 100 k 100 k 100 k 100 k
Main Channel
Sample Rate Setting (S/s)
100 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
50 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
20 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
10 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
5 M 100 k 100 k 100 k 100 k 100 k 100 k 50 k
2 M 100 k 100 k 100 k 100 k 100 k 50 k 20 k
1 M 100 k 100 k 100 k 100 k 50 k 20 k 10 k
500 k 100 k 100 k 100 k 50 k 20 k 10 k 5 k
200 k 100 k 100 k 50 k 20 k 10 k 5 k 2 k
100 k 100 k 50 k 20 k 10 k 5 k 2 k 1 k
50 k 50 k 10 k 10 k 5 k 2 k 1 k 500
20 k 20 k 10 k 5 k 2 k 1 k 500 200
10 k 10 k 5 k 2 k 1 k 500 200 100
5 k 5 k 1 k 1 k 500 200 100 50
2 k 2 k 1 k 500 200 100 50 20
1 k 1 k 500 200 100 50 20 10
500 500 100 100 50 20 10 5
200 200 100 50 20 10 5 2
100 100 50 20 10 5 2 1
50 50 10 10 5 2 1 –
20 20 10 5 2 1 – –
10 10 5 2 1 – – –
5 5 1 1 – – – –
If you set the sample rate (the main channel sample rate setting) of this instrument to a rate that
exceeds the sub channel data update rate, all data within the sub channel data update interval will
be the same.
Appendix 2 Relationship between the Main Channel Sample Rate, Sub Channel Data Update Rate, and Acquisition Memory Writing Rate
