4-CH 1 MS/s, 16-Bit Isolation Module
Rate at Which Data Is Written to the Acquisition Memory
Data Update Rate 1 MS/s
Main Channel
Sample Rate Setting (S/s)
100 M 1 M
50 M 1 M
20 M 1 M
10 M 1 M
5 M 1 M
2 M 1 M
1 M 1 M
500 k 500 k
200 k 200 k
100 k 100 k
50 k 50 k
20 k 20 k
10 k 10 k
5 k 5 k
2 k 2 k
1 k 1 k
500 500
200 200
100 100
50 50
20 20
10 10
5 5
GPS Input
Rate at Which Data Is Written to the Acquisition Memory
Data Update Rate 1 S/s
Main Channel
Sample Rate Setting (S/s)
100 M 100 k
50 M 100 k
20 M 100 k
10 M 100 k
5 M 100 k
2 M 100 k
1 M 100 k
500 k 50 k
200 k 20 k
100 k 10 k
50 k 5 k
20 k 2 k
10 k 1 k
5 k 500
2 k 200
1 k 100
500 50
200 20
100 10
50 5
20 2
10 1
5 –
: Some data will not be updated. If this occurs, previous data is displayed consecutively.
Appendix 2 Relationship between the Main Channel Sample Rate, Sub Channel Data Update Rate, and Acquisition Memory Writing Rate
