YOKOGAWA DL350 Getting Started Guide

App-24
IM DL35 O -03EN
Top
Menu
Item Value
Detail
Linear Scale OFF
CH1 to 4 (STRAIN_NDIS (701270), STRAIN_DSUB (701271))
Basic
V Range 20000 µSTR
BandWidth Full
Label Channel number
Sensor Setup 2 V/2.00
Display
Range Unit µSTR
Upper 20000 µSTR
Lower −20000 µSTR
Invert OFF
Display Group 1, M
Detail
Linear Scale OFF
CH1 to 4 (ACCL/VOLT (701275))
Basic
V/Div
1
50 V/div
V Range
2
500 V
Coupling DC
BandWidth Full
Probe 10:1
Label Channel number
Display
V Scale
1
DIV
Position
1
0.00 div
V Zoom
1
×1
Upper
2
250.0 V
Lower
2
−250.0 V
Invert OFF
Display Group 1, M
Detail
Linear Scale OFF
CH1 to 4 (FREQ (720281))
Basic
V/Div
1
1 kHz/div
V Range
2
10 kHz
FV Setup Frequency
Label Channel number
Input User
Display
V Scale
1
DIV
Position
1
0.00 div
V Zoom
1
×1
Upper
2
5000.0 Hz
Lower
2
−5000.0 Hz
Display Group 1, M
Detail
Linear Scale OFF
CH1 to 4 (16CH VOLT (720220))
Basic
V/Div
1
2 V/div
V Range
2
20 V
Coupling DC
BandWidth Full
Label Channel number
Display
V Scale
1
DIV
Position
1
0.00 div
V Zoom
1
×1
Top
Menu
Item Value
Upper
2
25.000 V
Lower
2
−25.000 V
Invert OFF
Display Group 1, M
Detail
Linear Scale OFF
CH1 to 4 (16CH TEMP/VOLT (720221))
Basic
Data Update Period 100 ms
V/Div
1
0.2 V/div
V Range
2
2 V
Coupling DC
Label Channel number
Display
V Scale
1
DIV
V Scale
2
SPAN
Position
1
0.00 div
V Zoom
1
×1
Upper
2
20000.0 mV
Lower
2
−20000.0 mV
Invert OFF
Display Group 1, M
Detail
Linear Scale OFF
CH1 to 6 (LOGIC (720230))
Basic
Label Channel number
Bit Setup
Display1 ON
Bit Name Bit number
Chatter Elimination OFF
Position
1
0.00 div
V Zoom ×1
Bit Mapping Auto
Display Group 1, M
CH1 to 4 (CAN MONITOR (720240))
CAN Port Config.
Port Setup
Bit Rate 500 Kbps
Sample Point 85%
Sync Jump Width 2
Bit Sample Num 1
Listen Only OFF
Terminator OFF
All SubChannel Setup
Input OFF
Label Channel number
Msg Fmt STD
ID (Hex) 000
Byte Count Auto
Start Bit 0
Bit Cnt 8
Byte Order Big
Value Type Unsign
All SubChannel Factor/Offset
Factor 1.0000
Offset 0.0000
Display
Sub Channel 1
Upper 400.00
Lower −100.00
Appendix 6 Default Values
