Appendix 6 Default Values
Top
Menu
Item Value
Display Group 1, M
One Shot Out
Message Format STD
ID (Hex) 000
Frame Data
DLC 0
Data (Hex) 00 00 00 00
00 00 00 00
CH1 to 4 (CAN & LIN (720241))
The values for CAN are the same as the values for
the 720240.
Lin Port Config.
Frame Setup
Bit Rate 19200 bps
Data Length 1
Check Sum Classic
All SubChannel Setup
Input OFF
Label Sub Channel Number
ID (Hex) 00
Start Bit 0
Bit Count 8
Byte Order Little
Value Type Unsign
All SubChannel Factor/Offset
Factor 1.0000
Offset 0.0000
Display
Sub Channel 1
Upper 400.00
Lower −100.00
Display Group 2
CH1 to 4 (SENT (720243))
SENT Format
Clock Tick 3.00 µs
Data Nibbles Number 6
Pause Pulse ON
CRC Type Recommended
Slow CH Type Enhanced (ID 8 bit +
Data12 bit)
Fast Channel Multiplexing
OFF
Error Channel Setup
Fast Channel CRC
Detect ON
Error Trigger ON
Error Count ON
Slow Channel CRC
Detect ON
Error Trigger ON
Error Count ON
Nibble Value
Detect ON
Error Trigger ON
Error Count ON
Successive Calibration Pulses (Option2)
Detect OFF
Error Trigger ON
Error Count ON
Pulse Number
Detect ON
Top
Menu
Item Value
Error Trigger ON
Error Count ON
Error Count Reset on Start
ON
Input Setup
Probe 1:1
Time Out 2000.0 ms
All SubChannel Setup
Sub Channel Number Data Type Input Label
1 FastCH ON CH<x>_F1
2 FastCH ON CH<x>_F2
3 FastCH ON CH<x>_F3
4 S&C ON CH<x>_SC
5 SlowCH ON CH<x>_S1
6 SlowCH ON CH<x>_S2
7 SlowCH ON CH<x>_S3
8 SlowCH ON CH<x>_S4
9 SlowCH ON CH<x>_S5
10 Error Trigger ON CH<x>_ET
11 Error Count ON CH<x>_EC
(When Data Type is FastCH)
Endian Big
Start Bit
Fast CH1 0
Fast CH2 0
Fast CH3 0
Bit Size 12
Value Type Unsign
(When Data Type is S&C)
Bit0
Display ON
Label Bit0
Bit1
Display ON
Label Bit1
Bit2
Display ON
Label Bit2
Bit3
Display ON
Label Bit3
V Zoom ×1.0
(When Data Type is SlowCH)
ID 0x00
Start Bit 0
Bit Size 12
All SubChannel Factor/Offset
(When Data Type is FastCH or SlowCH)
Factor 1.0000
Offset 0.0000
Unit “”
Display
Sub Channel 1
Upper 4.5000E+3
Lower −500.00
Display Group 4
Acquire (scope mode)
Basic
Time/div 10 ms/div
Record Length 10 k
