Input Modules (Sold Separately)
To make sure that an input module is the module that you ordered, check the module name written on
it.
Model Name Abbreviation
720211 High-Speed 100 MS/s, 12-Bit Isolation Module HS100M12
720250 High-Speed 10 MS/s, 12-Bit Isolation Module HS10M12
720254 4-CH 1 MS/s, 16-Bit Isolation Module 4CH 1M16
720268 Hi-Voltage 1 MS/s 16bit Isolation Module (with AAF, RMS) HV (with AAF, RMS)
701261 Universal (Voltage/Temp.) Module UNIVERSAL
701262 Universal (Voltage/Temp.) Module (with AAF) UNIVERSAL (AAF)
701265 Temperature, High Precision Voltage Isolation Module TEMP/HPV
720266 Temp./Hi-Prec. Voltage Module (Low Noise) TEMP/HPV
701270 Strain Module (NDIS) STRAIN_NDIS
701271 Strain Module (DSUB, Shunt-Cal) STRAIN_DSUB
701275 Acceleration/Voltage Module (with AAF) ACCL/VOLT
720281 Frequency Module FREQ
720220 16-CH Voltage Input Module 16CH VOLT
720221 16-CH Temperature/Voltage Input Module 16CH TEMP/VOLT
720230 Logic Input Module LOGIC
720240 CAN Bus Monitor Module* CAN MONITOR
720241 CAN & LIN Bus Monitor Module* CAN & LIN
720243 SENT Monitor Module SENT
* The CAN bus monitor, CAN&LIN bus monitor, and SENT monitor modules can be used on models
with the /VE (vehicle edition) option.
720250
HS10M12
Top line: Model
Bottom line: Abbreviation
In this manual, input modules are referred to by their model names and abbreviations.
For example, the High-Speed 10 MS/s, 12-Bit Isolation Module is referred to as the 720250 (HS10M12).
However, if a module has already been referred to previously, it may be referred to only by its model
name (for example, 720250).
