4-18
IM DL350E-17EN
4.1 List of Commands
Command Function page
:GONogo:ZONE:PATTern<x>:MODE
Sets or queries the specified determination pattern’s reference condition for
waveform zone determination.
4-112
:GONogo:ZONE:PATTern<x>:TRACe
Sets or queries the specified determination pattern’s determination waveform
for waveform zone determination.
4-113
:GONogo:ZONE:PATTern<x>:ZONE
Sets or queries the specified determination pattern’s source waveform zone
data for waveform zone determination.
4-113
GPS Group
:GPS?
Queries all GPS data acquisition settings. 4-114
:GPS:ALTitude?
Queries all settings related to obtaining altitude information from GPS data. 4-114
:GPS:ALTitude:DISPlay
Sets or queries whether the GPS altitude data channel is displayed. 4-114
:GPS:ALTitude:LABel
Sets or queries the label of the GPS altitude data channel. 4-114
:GPS:ALTitude:POSition
Sets or queries the position of the GPS altitude data channel. 4-114
:GPS:ALTitude:RANGe
Sets or queries the range of the GPS altitude data channel. 4-114
:GPS:ALTitude:SCALe
Sets or queries the scale of the GPS altitude data channel. 4-114
:GPS:DIRection?
Queries all settings related to obtaining direction information from GPS data. 4-114
:GPS:DIRection:DISPlay
Sets or queries whether the GPS direction data channel is displayed. 4-114
:GPS:DIRection:LABel
Sets or queries the label of the GPS direction data channel. 4-114
:GPS:DIRection:POSition
Sets or queries the position of the GPS direction data channel. 4-114
:GPS:DIRection:SCALe
Sets or queries the scale of the GPS direction data channel. 4-115
:GPS:DISPlay
Sets or queries whether the GPS channel is displayed. 4-115
:GPS:LATitude?
Queries all settings related to obtaining latitude information from GPS data. 4-115
:GPS:LATitude:DISPlay
Sets or queries whether the GPS latitude data channel is displayed. 4-115
:GPS:LATitude:LABel
Sets or queries the label of the GPS latitude data channel. 4-115
:GPS:LATitude:POSition
Sets or queries the position of the GPS latitude data channel. 4-115
:GPS:LATitude:SCALe
Sets or queries the scale of the GPS latitude data channel. 4-115
:GPS:LONGitude?
Queries all settings related to obtaining longitude information from GPS data. 4-115
:GPS:LONGitude:DISPlay
Sets or queries whether the GPS longitude data channel is displayed. 4-115
:GPS:LONGitude:LABel
Sets or queries the label of the GPS longitude data channel. 4-115
:GPS:LONGitude:POSition
Sets or queries the position of the GPS longitude data channel. 4-115
:GPS:LONGitude:SCALe
Sets or queries the scale of the GPS longitude data channel. 4-115
:GPS:MODE
Sets or queries whether GPS data will be acquired. 4-115
:GPS:STATus:BLABel<x>
Sets or queries the label string of the bit of the GPS status channel. 4-116
:GPS:STATus:DISPlay
Sets or queries whether the GPS status channel is displayed. 4-116
:GPS:STATus:LABel
Sets or queries the label of the GPS velocity data channel. 4-116
:GPS:STATus:POSition
Sets or queries the position of the GPS velocity data channel. 4-116
:GPS:STATus:ZOOM
Sets or queries the vertical zoom factor of the GPS status channel. 4-116
:GPS:VELocity?
Queries all settings related to obtaining velocity information from GPS data. 4-116
:GPS:VELocity:DISPlay
Sets or queries whether the GPS velocity data channel is displayed. 4-116
:GPS:VELocity:LABel
Sets or queries the label of the GPS velocity data channel. 4-116
:GPS:VELocity:POSition
Sets or queries the position of the GPS velocity data channel. 4-116
:GPS:VELocity:RANGe
Sets or queries the range of the GPS velocity data channel. 4-116
:GPS:VELocity:SCALe
Sets or queries the scale of the GPS velocity data channel. 4-116
HCOPy Group
:HCOPy?
Queries all screen capture data output settings. 4-117
:HCOPy:ABORt
Aborts the Long Print operation in progress on a Brother PocketJet printer. 4-117
:HCOPy:COMMent
Sets or queries the screen comment. 4-117
:HCOPy:EXECute
Performs printing on the USB printer. 4-117
:HCOPy:EXTPrinter?
Queries all USB printer output settings. 4-117
:HCOPy:EXTPrinter:MAG
Sets or queries the print magnification for printing data measured using an
external clock in Long Print mode on a Brother PocketJet printer.
4-117
:HCOPy:EXTPrinter:MODE
Sets or queries the output format for Brother PocketJet printers. 4-117
:HCOPy:EXTPrinter:RANGe
Sets or queries the output start point and output end point for printing to a
Brother PocketJet printer in Long Print mode.
4-117
:HCOPy:EXTPrinter:TDIV
Sets or queries the time axis (print magnification) setting for printing data
measured using the internal clock in Long Print mode on a Brother PocketJet
printer.
4-117
:HCOPy:EXTPrinter:TONE
Sets or queries the colors that will be used when printing from the HP Inkjet
printer.
4-117
:HCOPy:EXTPrinter:TYPE
Sets or queries the output command for the external printer connected
through USB.
4-118
