4. BASIC OPERATING PROCEDURES
4.6.10 Menu Tree
1 Device setup
2 PV [cr]
3 AO1 [cr]
4 Flow Span [r]
5 Mode [cr]
Online Menu
1 Process
variables
2 Diag/Service
3 Basic setup
1 PV [cr]
2 PV % rnge [cr]
3 A01 [cr]
4 Total [cr]
{5 temp} [cr]
{6 TV % rnge} [cr]
{7 A03} [cr]
1 Self/test status
2 Loop test [#]
3 Test output[#]
4 D/A trim[#]<H10, H11>
5 Scaled D/A trim[#]
1 Self test [#]
2 Status
1 Tag[u/d] <C10>
2 Easy setup [r&w]
1 Out analog[r&w]
2 Out pulse[r&w]
3 Out status
4 End
Status group 1[r] (*8)
Status group 2[r] (*9)
(Status group 3)[r] (*10)
to be continued to next page
[r] : read
[cr] : continuous read
[w] : write
[u/d] : upload/download data
[sel] : select
[#] : method
{ } : Only for
Option code /MV
< > : Parameter No.
in display and BRAIN
Terminal
( ) : Related parameter
Offline
Online
Frequency
Utility
New Configuration
Saved Cpnfiguration
Off [r&w sel]
On
1 Contact out[u/d][#] <B20>
2 Display mode <B30>
3 Totalizer <B31>
{4 Analog out select}[#]
Off
Scaled pulse
Unscaled pulse
Frequency
Alarm
Flow SW(Low:On)
Flow SW(Low:Off)
1 Pulse rate[r&w][u/d] <B21>
1 Frequency at 100%[r&w][u/d]<B22>
1 Setting level[r&w][u/d]
1 Upper display[u/d]<B30>
2 Lower display[u/d]<B31>
Flow rate(%) [r&w sel]
Flow rate
{Temp (%)}
Blank [r&w sel]
Total
{Temp}
1 Total[cr] <A30>
2
Total start/stop[u/d]<B40>
3 Total rate[r&w][u/d]<B45>
4 Total reset[w,#]
Stop [r&w sel]
Start
Flow
Temp
1 Temp unit[u/d] <D20>
2 Temp 0% [r&w][u/d]<B51>
3
Temp 100% [r&w][u/d]<B52>
4 Temp error out[u/d]<F58>
5 End
0% [r&w sel]
Out limit(H)
Process temp
(*5)
F040608_1.EPS
<A20>
<A10>
<A30>
<A41>
<A40>
<J10>
<J20>
<J30>
<B50>
<B47>
<B23>
