YOKOGAWA EJX Series User Manual

  <8.ParameterSummary>
46
IM01C25A01-01E
No. Parametername Item
R/W
*1
Content Defaultvalue
Applicablemodel
Upload
data
F P L
M20 ISOLMATL Capsulematerial W
  
—
M21 FILLFLUID Filluid W
  
—
M22 GASKETMATL Gasketmaterial W
  
—
M23 PROCONMATL Flangematerial W
  
—
M24 D-VENTMATL Ventplugmaterial W
  
—
M25 PROCONTYPE Processconnection
type
W
  
—
M26 RSISOLMATL Remotesealmaterial W
  
—
M27 PROCONSIZE Flangesize W
  
—
M28 NUMRS Numberofremoteseal W
  
—
M29 RSFILLFLUID Filluidofremoteseal W
  
—
M30 RSTYPE Remotesealtype W
  
—
M50 MSCODE1 Modelandsufxcode1 W
  
—
M51 MSCODE2 Modelandsufxcode2 W
  
—
M52 MSCODE3 Modelandsufxcode3 W
  
—
M53 MSCODE4 Modelandsufxcode4 W
  
—
M54 MSCODE5 Modelandsufxcode5 W
  
—
M55 MSCODE6 Modelandsufxcode6 W
  
—
M60 SELFCHECK Self-diagnostics R SeeA60
  
—
P Record Historyoferrors
P10 ERRORREC1 Lasterror W SeeA60 GOOD
  
—
P12 ERRORREC2 Secondrecenterror W SeeA60 GOOD
  
—
P14 ERRORREC3 Thirdrecenterror W SeeA60 GOOD
  
—
P16 ERRORREC4 Forthrecenterror W SeeA60 GOOD
  
—
P60 SELFCHECK Self-diagnostics R SeeA60
  
—
T CHARACTERIZR Signalcharacterizer
setting
T10 S.C.ENABLE Signalcharacterizer
permission
W INHIBITorENABLE INHIBIT
  
—
T11 NUMOFPOINT Numberofcoordinates W 0to9 0
  
—
T20 XSTART(FIX) StartpointofX R 0.00%
  
—
T21 YSTART(FIX) StartpointofY R 0.00%
  
—
T22 X1 Coordinate1ofX W 0.00to100.00% 10.00
  
—
T23 Y1 Coordinate1ofY W 0.00to100.00% 10.00
  
—
T24 X2 Coordinate2ofX W 0.00to100.00% 20.00
  
—
T25 Y2 Coordinate2ofY W 0.00to100.00% 20.00
  
—
T26 X3 Coordinate3ofX W 0.00to100.00% 30.00
  
—
T27 Y3 Coordinate3ofY W 0.00to100.00% 30.00
  
—
T28 X4 Coordinate4ofX W 0.00to100.00% 40.00
  
—
T29 Y4 Coordinate4ofY W 0.00to100.00% 40.00
  
—
T30 X5 Coordinate5ofX W 0.00to100.00% 50.00
  
—
T31 Y5 Coordinate5ofY W 0.00to100.00% 50.00
  
—
T32 X6 Coordinate6ofX W 0.00to100.00% 60.00
  
—
T33 Y6 Coordinate6ofY W 0.00to100.00% 60.00
  
—
T34 X7 Coordinate7ofX W 0.00to100.00% 70.00
  
—
T35 Y7 Coordinate7ofY W 0.00to100.00% 70.00
  
—
T36 X8 Coordinate8ofX W 0.00to100.00% 80.00
  
—
T37 Y8 Coordinate8ofY W 0.00to100.00% 80.00
  
—
T38 X9 Coordinate9ofX W 0.00to100.00% 90.00
  
—
T39 Y9 Coordinate9ofY W 0.00to100.00% 90.00
  
—
T40 XEND(FIX) EndpointofX R 100.00%
  
—
T41 YEND(FIX) EndpointofY R 100.00%
  
—
T60 SELFCHECK Self-diagnostics R SeeA60
  
—
*1: R/W:R=Readonly,W=Read&Write
*2: ThedefaultvalueshowsMWP(Maximumworkingpressure)ofthecapsule.
SincetheworkingpressurelimitvariesaccordingtotheModel,refertotheGeneralSpecicationssectionineachuser’smanual.
