YOKOGAWA MuR10000 User Manual

13IM 04P01B01-02E
Panel Cutout
+2
0
+2
0
+2
0
L
+2
0
L
+2
0
L (mm)
2 282
426
570
714
858
1002
1146
1290
1434
(144xn)-6
3
4
5
6
7
8
9
10
n
137
(5.39)
137
(5.39)
+2
0
137
(5.39)
137
(5.39)
Units
175 min.
(6.89)
175 min.
(6.89)
Unit: mm (approx. inch)
Unless otherwise specified, tolerance is ±3%
(however, tolerance is ±0.3 mm when below 10 mm).
Attach the mounting brackets to the top and bottom when
mounting the recorders side-by-side horizontally or right and
left when mounting the recorders side-by-side vertically.
Side-by-Side Mounting
(vertically, max. 3 units)
Side-by-Side Mounting
(horizontally)
Single-Unit Mounting
External Dimensions of the Portable Type (/H5x Option)
138.5 (5.45)
144 (5.67)
141.5 (5.57)
12.4 (0.49)
144 (5.67)
187 (7.36)
27.5
(1.08)
285 (11.2)
176 (6.93)
81.5 (3.21)
100-240V~
50/60Hz
40VA MAX
Unit: mm (approx. inch)
Unless otherwise specified, tolerance is ±3%
(however, tolerance is ±0.3 mm when below 10 mm).
Installing/Wiring the Recorder
