CE: Chart end
Alarm Output Relay Terminals and FAIL/Chart End Output Relay Terminals
NC (Normally Closed), C (Common), NO (Normally Opened)
Alarm output terminals 01 to 06 are expressed as I01 to I06 in the alarm output relay
settings.
Remote Control Input Terminals
1 to 5 (Remote control input terminals), C (Common)
Remote control input terminals 1 to 5 are expressed as numbers 1 to 5 in the remote
control input settings.
Transistor input
(Open collector)
Relay contact input
(Voltage-free contact)
123
45
C
123
45
C
Relay contact output
C
NO
NC
Alarm output
FAIL/chart end output
Remote control input
Relay Contact Output Specifications
Output format: Relay contact
Contact rating: 250 VAC (50/60 Hz)/3 A, 250 VDC/0.1 A (for resistor load)
Dielectric strength: 1500 VAC at 50/60 Hz for one minute (between output terminals
and the ground terminal)
Relay Contact Input/Transistor Input Specifications
• Voltage-free contact: Contact closed at 200 Ω or less and contact open at 100 kΩ
or greater
• Open collector: 0.5 V or less (30 mADC) when turned ON, leakage current of
0.25 mA or less when turned OFF
Input format: Photocoupler isolation (shared common)
Dielectric strength: 500 VDC for one minute between input terminals and the ground
terminal
Installing/Wiring the Recorder
