54 IM 04P01B01-02E
RS-422A/485 communication interface function (/C3 option).
Setup Item Pen/Dot Selectable Range or Selections Default Value
RS-422/485 > Address - 1 to 32 1
RS-422/485 > Baud rate - 1200/2400/4800/9600/19200/38400 9600
RS-422/485 > Data length - 7/8 8
RS-422/485 > parity - Odd/Even/None Even
RS-422/485 > Protocol - NORMAL/MODBUS NORMAL
Ethernet communication interface function (/C7 option)
Setup Item Pen/Dot Selectable Range or Selections Default Value
Ethernet > Host > Host - 64 characters or less Blank
Ethernet > Host > Domain - 64 characters or less Blank
Ethernet > Local IP > A - IP address 0.0.0.0
Ethernet > Local IP > M - IP address (Subnet mask) 0.0.0.0
Ethernet > Local IP > G - IP address (Default gateway) 0.0.0.0
Ethernet > DNS > DNS - On/Off Off
Ethernet > DNS > P - IP address (Primary DNS sever) 0.0.0.0
Ethernet > DNS > S - IP address (Secondary DNS sever) 0.0.0.0
Ethernet > DNS > Suffix_P - Primary domain suffix Blank
Ethernet > DNS > Suffix_S - Secondary domain suffix Blank
Ethernet > Login > Login - Use/Not Not
Ethernet > LoginSet > Level - Admin/User1 to User6 Admin
Ethernet > LoginSet > Register - On/Off Admin and User1
are On
Ethernet > LoginSet > User - 16 characters or less Admin: admin
User1 to 6: user1 to
user6
Ethernet > LoginSet > Password - 4 characters or less Administrator: 0
User1 to 6: 1 to 6
Ethernet > Timeout > Timeout - On/Off Off
Ethernet > Timeout > Duration - 1 to 120 min 1 min
Ethernet > K. Alive > Keep alive - On/Off On
Calibration correction (/CC1 option)
Setup Item Pen/Dot Selectable Range or Selections Default Value
Calibration > Channel - 01 to 06 01
Calibration > Mode - Revise Value, Absolute Value Revise Value
Calibration > Point - 2 to 16 2
Customized Menu
Setup Item Pen/Dot Selectable Range or Selections Default Value
Cust. menu > Cust. menu - Not/Use Not
Cust. menu > Password - Numbers and spaces within 4 digits Blank
Cust. menu > P_Adj - On/Off Off
Select menu > Set mode > Range - On/Off On
Select menu > Set mode > Bias - On/Off On
Select menu > Set mode > Alarm - On/Off On
Select menu > Set mode > Unit - On/Off On
Select menu > Set mode > Chart speed - On/Off On
Select menu > Set mode > Aux - On/Off On
Select menu > Set mode > Calibration - On/Off On
Select menu > Set mode > Math - On/Off On
Select menu > Set mode > Batch name - On/Off On
Select menu > Set mode > Batch detail - On/Off On
Select menu > Function > Manual print - On/Off On
Select menu > Function > Setup list - On/Off On
Select menu > Function > Message - On/Off On
Select menu > Function > Buffer clear - On/Off On
Select menu > Function > Periodic - On/Off On
Setup Items and Default Values
