<APPENDIX 1. LIST OF PARAMETERS FOR EACH BLOCK OF RAMC>
A-1
All Rights Reserved. Copyright © 2006, Rota Yokogawa
IM 01R01B02-01E-E 5th edition October 01, 2020 -00
Appendix 1. List of Parameters for each
Block of RAMC
NOTE
• With Factory Reset (setting: 1) the parameters OUT_SCALE and PV_SCALE must be recongured.
• When changing ow units, the parameter PV_SCALE must be recongured.
• Changes to the process variables between mass- and volume ow also require a change of the parameter
CHANNEL in the AI block to make this change available in the OUT parameter.
• To avoid unusable alarm status information, the upper alarm/warning limits must always be above the lower
alarm/warning limit.
Legend:
• "-": not dened
• "n.a.": not applicable
• R: Read
• W: Write
A1.1 Physical Block
Block name Physical Block
Slot 0
Abs.
Index
Parameter Sub-
Parameter
Label Data Type/
Structure
Read/
Write
Initial value Functional Description
16 BLOCK_OBJECT - DS-32 R/- - Indicates the following block
characteristics
Reserved - Unsigned8 R/- 250: Not used For future use (not available)
Block_Object Block Object Unsigned8 R/- 0x01: Physical Block Kind of block
Parent_Class Parent Class Unsigned8 R/- 0x01: Transmitter Superior device classication
Class Class Unsigned8 R/- 0x06: Variable Area
Flow Meter
Device classication
Dev_Rev Device Revision Unsigned16 R/- 1 Assigned device driver versions
(e.g. EDD)
Dev_Rev_Comp Device Revision
Compatibility
Unsigned16 R/- 1 Lowest device revision supported by
the device
DD_Revision - Unsigned16 R/- 1 For future use (not available)
Prole Prole OctetString R/- 0x40: PROFIBUS PA
Prole for Process
Control Devices,
0x02: Compact
Class B
Used Prole
Prole_Revision Prole Revision Unsigned16 R/- 0x0302: Version 3.02 Used Prole version
Execution_Time - Unsigned8 R/- 0 For future use (not available)
Number_of_
Parameters
No. of Parameters Unsigned16 R/- 39 Number of used parameters
Address_of_
View_1
- Unsigned16 R/- 0x00E6: slot 0, index
230
Reference to View_1 parameter
Number_of_Views - Unsigned8 R/- 2 Number of Views available
17 ST_REV Static Revision No. Unsigned16 R/- 0 Indicates the revision level of the
described block. Increments each
time a static parameter (S) changes
18 TAG_DESC TAG OctetString R/W RAMC-PA_P or det.
by ordered scale
Block specic TAG for customer use
19 STRATEGY Strategy Unsigned16 R/W 0 User-specied value e.g. for congu-
ration or diagnostics as a sorting key
