YOKOGAWA ROTAMETER RAMC User Manual

<APPENDIX 1. LIST OF PARAMETERS FOR EACH BLOCK OF RAMC>
A-2
All Rights Reserved. Copyright © 2006, Rota Yokogawa
IM 01R01B02-01E-E 5th edition October 01, 2020-00
Abs.
Index
Parameter Sub-
Parameter
Label Data Type/
Structure
Read/
Write
Initial value Functional Description
20 ALERT_KEY Alert Key Unsigned8 R/W 0 User-specied value for event alloca-
tion e.g. identication of the plant unit
21 TARGET_MODE Target Mode Unsigned8 R/W 0x08: AUTO
(permitted bit only!)
Indicates and sets the target mode of
the block
22 MODE_BLK - DS-37 R/- - Indicates block mode overview by
sub-parameters
Actual Actual Mode Unsigned8 R/- 0x08: AUTO
(permitted bit only!)
Indicates the current mode
Permitted - Unsigned8 R/- 0x08: AUTO
(permitted bit only!)
Indicates possible modes
Normal - Unsigned8 R/- 0x08: AUTO
(permitted bit only!)
Indicates the usual mode during
normal operation
23 ALARM_SUM - DS-42 R/- - Maintain alert status by sub-parameters
Current Current State
Alarm Sum
OctetString R/- 0x0000: No Alarm
(no modication
indicated)
Indicates Update Events (static
parameter modication)
Unacknowledged - OctetString R/- 0 For future use (not available)
Unreported - OctetString R/- 0 For future use (not available)
Disabled - OctetString R/- 0 For future use (not available)
24 SOFTWARE_
REVISION
Software Revision Visible
String
R/- E.g.: V3.40.2.21846 Indicates revision-number of the
software of the eld device.
25 HARDWARE_
REVISION
Hardware Revision Visible
String
R/- E.g.: cM-MBP V1.04 Indicates revision-number of the
hardware of the eld device.
26 DEVICE_MAN_ID Manufacturer Unsigned16 R/- 0x0037: Yokogawa Indicates the eld device manufacturer
27 DEVICE_ID Device Id Visible
String
R/- Rotameter RAMC Indicates the name of the eld device
28 DEVICE_SER_
NUM
Device Serial Num Visible
String
R/- E.g.: commMod
173200252
Indicates the serial number of the
communication module.
29 DIAGNOSIS Diagnosis Octet String R/- 0x00,0x00,0x00,
0x00
Shows diagnostic device information
(simultaneous messages possible)
30 DIAGNOSIS_
EXTENSION
Diagnosis
Extension
Octet String R/- 0x00,0x00,0x00,
0x00,0x00,0x00
Shows additional diagnostic device
information
31 DIAGNOSIS_
MASK
Diagnosis Mask Octet String R/- Condensed:
0x00,0xB8,0x0F,
0x80
Classic: 0x1B, 0xB8,
0x00,0x80
Denition of supported DIAGNOSIS
bits.
32 DIAGNOSIS_
MASK_
EXTENSION
Extended Diagnosis
Mask
Octet String R/- 0xBF,0x5F,0x79,
0x00,0x00,0x00
Denition of supported DIAGNOSIS_
EXTENSION bits
34 WRITE_LOCKING Write Locking Unsigned16 R/W 2457: Disabled Enables write lock to acyclic write
service until reversed (see chapter
4.5)
35 FACTORY_
RESET
Factory Reset Unsigned16 R/W 0: No Function Enables different kinds of factory
resets
36 DESCRIPTOR Descriptor Octet String R/W - User dened string for device
description
37 DEVICE_
MESSAGE
Message Octet String R/W - User dened string for device
description
38 DEVICE_
INSTAL_DATE
Installation Date Octet String R/W - Date of installation of the device
40 IDENT_NUMBER_
SELECTOR
Ident Number
Selector
Unsigned8 R/W 127: Adaption mode Enables Ident_Number selection
42 FEATURE - DS-68 R/- - Indicates supported and enabled
status and diagnosis device features
Supported FEATURE_
Supported
Octet String R/- 0x03,0x00,0x-
00,0x00
Indicates supported status and
diagnosis information
Enabled FEATURE_
Enabled
Octet String R/- 0x01,0x00,0x-
00,0x00
Indicates enabled status and diagno-
sis information
43 COND_STATUS_
DIAG
Condensed
Status/Diagnosis
Unsigned8 R/W 1: Condensed Status
and Diagnosis
Setting and indication of status and
diagnostic device mode
44 DIAG_EVENT_
SWITCH
- Diag_
Event_
Switch
R/W - Indicates and controls device's event
reactions (if FEATURE_Enabled -->
Condensed Status = 1)
Diag_Status_Link - Array of
Unsigned8
R/W - Array of switches for each specic
event
Status Mapping: Unsigned8
(low nibble)
R/W According to default Allows user specic status control
Diagnosis
Mapping:
Unsigned8
(high nibble)
R/W According to default Allows user specic diagnosis control
Slot - Unsigned8 R/W 0 Not used
Index - Unsigned8 R/W 0 Not used
